Dingo® TX 700 Track Loader, Wide

Model: 22352

TX 700 wide track loader left side with a grapple rake attachment

Dingo® TX 700 Track Loader, Wide

Model: 22352

Model: 22352 UPC/EAN: 21038223520

Key Features

  • Compact footprint
  • Patented traction control
  • Camso track system with less aggressive tread pattern that minimises turf damage
Find a Dealer

Product Details

Designed to give you more power in a compact package, the Toro® Dingo® TX 700 expands labour savings beyond just homeowner projects. This no-nonsense workhorse packs 317 kg of rated operating capacity in a smaller footprint, so it’s ideal for projects where homeowners and contractors are working in confined spaces.
TX700 hauling rock going through trees
Smaller Footprint
Packs 317 kg of rated operating capacity in a smaller footprint, making it ideal for projects where homeowners and contractors need to reach tight areas or work in confined spaces.
Dingo TX700 white male operating with a bucket
Easy Operation
Featuring patented Dingo TX 1000 traction controls and a dedicated stand-on platform, the Dingo TX 700 is easy to use and offers increased comfort and visibility to the operator.
Dingo TX700 tracks
Gentle On Turf
Available in both narrow track and wide track configurations, the Dingo TX 700 is equipped with the industry-tested Camso track system – which features a less aggressive tread pattern that minimises turf damage.
Dingo TX700 using the level attachment to smooth dirt
Job Versatility
Compatible with dozens of attachments, including multiple types of buckets, adjustable forks, a grapple, leveller, utility blade and more, the Dingo TX 700 can be used for a wide range of jobs.

Air Filter

Dual Element

Cooling System

Combo Downflow Radiator and Cooler Oil Cooler

Dump Angle

42 deg

Dump Height

134.4 cm

Engine Displacement

1,262 cc

Engine Horsepower

18.4 kW (24.7 hp) @ 3,000 rpm

Engine Make

Yanmar

Engine Model

3TNV80F

Fuel Tank

20.8 litres

Fuel Type

Diesel

Ground Clearance

13.3 cm

Ground Pressure

44.1 kPa (6.4 psi)

Ground Speed - Forward

Up to 4.3 mph

Ground Speed - Reverse

Up to 4 mph

Height

140.5 cm

Height - With Bucket

140.5 cm

Hinge Pin Height

186.7 cm

Hydraulic Flow - Auxiliary

51.9 L/min

Hydraulic Flow - Traction

54.9 L/min

Hydraulic Pressure

207 bar (3,000 psi)

Length

208.3 cm

Length - With Bucket

261.3 cm

Loader Arms

Radial

Max Operating Height

246.3 cm

Oil Capacity

3.4 litres

Rated Operating Capacity*

321.1 kg

Reach - Fully Raised

78.7 cm

Reservoir Capacity

37.8 litres

Tip Capacity

918 kg

Track Length

23.1 cm

Track Width

321.5 cm

Tracks

MERT Track With Turf Friendly Style Tread

Traction

Dual Hydrostatic Pump

Weight

1,298 kg

Wheelbase

99 cm

Width

102.1 cm

Width - With Bucket

105.2 cm

Disclaimer

*Per ISO 14397-1
PREMIUM ENGINE OIL 10W30 (55 GAL) (Part number 121-6392)
PREMIUM ENGINE OIL 10W30 (5 GAL) (Part number 121-6393)
PREMIUM ENGINE OIL 15W40 (55 GAL) (Part number 121-6394)
PREMIUM ENGINE OIL 15W40 (5 GAL) (Part number 121-6395)
PX HYD FLUID (5 GAL) (Part number 133-8086)
Toro 55 Gallon PX Extended Life Hydraulic Fluid
Toro 55 Gallon PX Extended Life Hydraulic Fluid (Part number 133-8087)
Toro 55 Gallon PX Extended Life Hydraulic Fluid. Designed for use in Toro equipment created by Toro engineers. If you are unsure of your equipment needs, do a model extreme serial number search to verify that this is the correct oil type for your equipment.
PX HYDRAULIC FLUID-4 PK GALLON (Part number 138-9460)
Metal Hood Kit (Part number 163-8681)
Bucket
Loader Bucket Attachment 113 Litres (Part number 22340)
Use this standard bucket for moving rock, dirt, sand or other materials off and around the job site. The hardened steel cutting edge offers improved cutting and digging capability for better performance to handle tough digging conditions and affords superior wear. Capacity = 1 m³ (4 cubic feet)
Adjustable Forks, TX 1000 Compact Utility Loaders (Part number 22341)
Standard Bucket
Loader Bucket Attachment (Part number 22409)
Use this standard bucket for moving rock, dirt, sand or other materials off and around the job site. The hardened steel cutting edge offers improved cutting and digging capability for better performance to handle tough digging conditions and affords superior wear. Capacity = 1 m³ (4 cubic feet)
Light material bucket attachment
Light Materials Loader Bucket Attachment (Part number 22410)
Designed for moving light materials like chip-bark, mulch, snow and loam. The larger capacity bucket, 0.2 m³, is great for handling larger loads of lighter materials. The hardened steel cutting edge allows for improved cutting and digging capability for better performance to handle tough digging conditions and affords superior wear.
Utility Blade Attachment
Utility Blade Attachment (Part number 22414)
The Toro Dingo hydraulic blade greatly increases the versatility of your Dingo system. This incredibly versatile attachment can be used for a variety of earth or snow moving jobs. Fill trenches where rows of trees have been planted or irrigation pipes have been installed. Keep your hydraulic blade working in the winter by pushing snow from pavements in one pass.
Bore Drive Head Attachment
Bore Drive Head Attachment (Part number 22420)
The Toro® Dingo® boring unit allows you to dig under pavements and driveways to simplify irrigation and cable installations. Shorter rod lengths and the ability to lower the bore head below grade allow you to work in both confined and open areas, increasing your productivity.
Rod and Reamer
Rod and Reamer Kit (Part number 22421)
Easily bore under driveways and pavements to simplify irrigation and cable installations. Use with Bore Drive Head attachment model 22420. Working depth: 48 cm. Bits and reamers up to 8.9 cm (3.5") in diameter.
Multi-Purpose Tool, Dingo (Part number 22423)
Power Box Rake Attachment
Power Box Rake Attachment (Part number 22426)
The Toro Power Box Rake is the perfect tool for seed bed and sod bed preparation. The rotary drum on the power box rake pulverizes rough soil, cuts high spots and fills low spots in one pass; while removing rocks and debris. Pure carbide teeth design produces the best possible seeded sub-soil, which promote superior moisture retention and rapid seed growth.
Dingo Stump Grinder Attachment
Stump Grinder Attachment (Part number 22429)
The Toro® Dingo® Stump Grinder easily attaches to either Dingo or Dingo TX compact utility loaders. Make grinding stumps quicker and more productive with the stump grinder attachment for your Toro Dingo.
Tree Fork Attachment
Tree Fork Attachment (Part number 22438)
The Toro Dingo hydraulic tree forks can help you plant trees and large shrubs quickly and effortlessly, plus move all sorts of materials around your garden center or nursery. The Dingo Compact Utility Loader is especially easy to manoeuvre, helping you transport and position trees or shrubs exactly where you want them.
Cement mixing bowl attachment
Cement Mixer Attachment (Part number 22442)
This unique attachment will mix and pour up to 200 pounds (90.7 kg) of dry cement. The specially designed auger flighting inside the cement bowl keeps the cement in the bowl during mixing. This same auger design permits cement to be poured into fence post holes with the posts in place!
Tiller Attachment
Tiller Attachment (Part number 22445)
The Toro Dingo tiller attachment greatly increases the productivity and performance of your Dingo system. Break through hard soil conditions up to 15 cm (6") deep. Avoid clogging the tiller by using one easy hand control to reverse the direction of the tiller to clear jams from rocks and debris.
Empty Image Container
Trencher Crumber (Part number 22464)
Spring design, trencher accessory to help clean out trenches
Trench Filler, Compact Utility Loader (Part number 22472)
High Torque Trencher Attachment
High Torque Trencher Attachment (Part number 22473)
High-torque trencher head with heavy-duty drive system guarantees performance in the toughest soil conditions from rock to caliche. Dig trenches up to 127cm below grade. Heavy-duty nose roller bearing and reversible abrasion-resistant boom give you years of dependable use.
High Speed Trencher Head Attachment
High Speed Trencher Attachment (Part number 22474)
Ideal for fast, efficient trenching in most soil conditions. Great for cable, pipe or irrigation installations.
Empty Image Container
Trencher Crumber (Part number 22477)
Trencher accessory to help clean out trenches
4 in 1 Bucket
4-in-1 Bucket Loader Bucket Attachment (Part number 22478)
Designed to be used on the Dingo 323, 320-D, e-Dingo, TX 427, TX 525 and TX 1000 models, this attachment offers the versatility of 4 attachments. Use as a standard bucket, a leveler, a grapple rake and a blade.
narrow bucket attachment
Narrow Loader Bucket Attachment (Part number 22520)
Handle compact construction and remodelling sites by moving through 91.4cm gates without a problem. This 87.6cm wide bucket allows you to get through narrow spaces, including gates and doorways. Move rock, dirt, sand or other materials off and around the job site. Great for use on any Dingo® model equipped with narrow wheels and tyres.
Standard Bucket with Spacer (Part number 22522)
Grapple Rake Attachment
Grapple Rake Attachment (Part number 22577)
The Toro grapple rake attachment allows operators to grab, drag, lift, and place materials with ease. The grapple has two heavy-duty cylinders capable of producing 1361 kg of clamping force at the tine tips, insuring you can "grab-ahold" and not let go.
DINGO SNOW THROWER (Part number 22585)
Grapple Bucket
Grapple Bucket Attachment (Part number 22590)
Designed for contractors looking for a bucket to grab, drag, lift and remove materials on residential, commercial and demolition sites. Designed to be used on the Dingo 323, 320-D, e-Dingo, TX 427, TX 525, TX 1000 and e-Dingo models.
FLOOR SCRAPER (Part number 22673)
Swivel auger power head attachment
High Torque Auger Attachment (Part number 22805)
In any drive head, there is a trade-off between torque (power) and speed (revolutions per minute). The high torque head provides a large amount of torque to the auger at a slower speed. The high torque translates into the Dingo's capability to dig 30" (76.2 cm) holes up to 6' (1.8 m) deep in clay, gravel, sandstone and many other conditions where lower torque heads get stuck.
Swivel auger power head attachment
Track Loader Auger Attachment (Part number 22806)
This attachment swivels in all directions to create plumb holes on uneven terrain. The higher speed of this auger power head is ideal for augers up to 24" (61cm) in diameter. Quickly change between auger bit sizes to dig holes for fence posts, footings, irrigation heads and more!
Empty Image Container
18" Auger Bit (Part number 22814)
18" Auger Bit, requires 22805 or 22806
Empty Image Container
24" Auger Bit (Part number 22815)
24" Auger Bit, requires 22805 or 22806
Empty Image Container
30" Auger Bit (Part number 22816)
30" Auger Bit, requires 22805 or 22806
Empty Image Container
12" Auger Extension (Part number 22818)
12" Auger Extension - add onto any auger to increase depth
Empty Image Container
24" Auger Extension (Part number 22819)
24" Auger Extension - add onto any auger to increase depth
Empty Image Container
6" Full Flight Auger Bit (Part number 22820)
6" Full Flight Auger Bit - requires 22805 or 22806
Empty Image Container
9" Full Flight Auger Bit (Part number 22821)
9" Full Flight Auger Bit - requires 22805 or 22806
Empty Image Container
12" Full Flight Auger Bit (Part number 22822)
12" Full Flight Auger Bit - requires 22805 or 22806
Empty Image Container
15" Full Flight Auger Bit (Part number 22823)
15" Full Flight Auger Bit - requires 22805 or 22806
Vibratory Plough Attachment
Vibratory Plough Attachment (Part number 22911)
The Toro® Dingo® vibratory plow attachment greatly reduces a contractor's time spent on irrigation and cable installations. Exclusively designed and built by Toro specifically for use on the Dingo, the vibratory plow optimizes pipe-pulling performance while minimizing turf damage during an installation. Also, use the chuted blade and spool carrier to install wire or cable.
Soil Cultivator Attachment
Soil Cultivator Attachment (Part number 23102)
The soil cultivator is the ultimate attachment for soil preparation! This incredibly versatile attachment can be used to cultivate and level soil as well as blend landscape materials, compost and fertiliser. This attachment will also bury debris such as stones, soil clods and grass. It transforms rough terrain into a perfect planting bed in one pass.
Concrete Breaker, Dingo Compact Utility Loaders (Part number 23135)
Leveller Attachment
Leveller Attachment (Part number 23165)
This versatile and highly productive tool is a must-have attachment for all job sites. Use to grade, finish, and spread landscape materials, backfill trenches, and break up the turf. Also great for carrying and transporting materials around the job site.
30IN STANDARD BUCKET (Part number 23174)
30IN PALLET FORK (Part number 23175)
30IN GRAPPLE (Part number 23176)
Red Paint - Gallon Can (Part number 361-11)
PAINT-SPRAY, TORO SEMI-GLOSS BLACK (Part number 361-9)
Red Paint - Quart Can (Part number 5340)
416815872-999999999 415300000-416815871 415287954-415299999 412900000-415287953 400000000-412899999

For complete product warranty information, contact Toro Customer Service

22352 Product Warranty

**See dealer for Warranty details.
