60 in. (152 cm) TITAN® Zero Turn Mower
60 in. (152 cm) TITAN® Zero Turn Mower
Product Information
- Model #: 76605
- Serial #: 400000000 - 415399999
- Product Type: Riding Products
Search for a part within assembly drawings:
Showing Results
| Drawing Title | Part Number | Description |
|---|---|---|
| Title |
Model #
76605
Serial #
400000000 - 415399999
Product Name
60 in. (152 cm) TITAN® Zero Turn Mower
Product Brand
Toro
Product Type
Riding Products
Product Series
Zero Radius Turn, Consumer
Chassis Type
ZRT - Consumer
Swath
60 inch / 152 cm
Discharge
Side Discharge
Engine/Motor Manufacturer
Kawasaki
Engine/Motor Size
24 hp
Engine/Motor Type
4 Cycle
Engine Starter
Electric
Transmission Type
Hydrostatic
Traction Type
Rear WD
Engine: Battery
12V 300CCA
Engine: Engine Speed
3600±100 RPM
Engine: Spark Plug
NGK BPR4ES
Engine: Spark Plug Gap
.030"/ .76mm
Chassis: Tire Pressure
13 psi / 90 kPa
Drive System: Ground Speed
Fwd. 0 - 8 mph
Chassis: Height of Cut Range
1.5"- 5", 1.2" increments
Engine: Ignition Coil Air Gap
0.011in (0.3mm)
Engine: Engine Oil Type
71 oz. (2.1L) 10w-30 with filter change
Drive System: Gearbox Lubricant
HYPR-OIL 500 / 20w-50 Synthetic Motor Oil
