Power Max Heavy Duty 926 OXE Snowthrower
Product Information
- Model #: 38664
- Serial #: 314000001 - 314999999
- Product Type: Snowthrowers
Loading...
-
Service Manual
-
Operator's Manual
-
Addendum
Snow Cab (Part # 107-3814)
Weight Kit (Required with Snow Cab) (Part # 107-3815)
26" Drift Breaker (Part # 107-3816)
Engine Maintenance Kit (Part # 138-0704)
Non-Marking Skid Kit, Power Max Snowthrower (Part # 38211)
Tire Chain Kit, Snowthrowers with 16in (4.80-8) Tires (Part # 38215)
TORO SNOW OIL 0W30 SYNTHETIC-20 OZ BT (Part # 38913)
Toro 2-Stage Cover (Part # 490-7466)
Plain 2-Stage Cover (Part # 490-7467)
-
Model #
38664 -
Serial #
314000001 - 314999999 -
Product Name
Power Max Heavy Duty 926 OXE Snowthrower -
Product Brand
Toro -
Product Type
Snowthrowers -
Product Series
Snowthrower, PowerMax HD -
Chassis Type
Two Stage -
Swath
26 inch -
Discharge
Two Stage -
Engine/Motor Manufacturer
Toro -
Engine/Motor Size
265cc -
Engine/Motor Type
4 Cycle -
Engine Starter
Electric/Recoil -
Transmission Type
Friction Disc -
Traction Type
2wd
-
Drive System: Gearbox Lubricant
4.5 oz. (133ml) SAE 90 GL5 or higher -
Engine: Spark Plug Gap
.030"/ .76mm -
Chassis: Tire Pressure
17-20 PSI / 116-137 kPa -
Engine: Engine Speed
3300±100 RPM -
Engine: Spark Plug
Champion RN9YC / NGK BPR6ES / NHPS F7RTC (OEM China) -
Engine: Engine Oil Type
30-32 oz. 5w-30 synthetic or 5w-30 below 40F (4c) or 10w-30 above 0F (-20c)
