Power Max 1028 LXE Snowthrower

Product Information

  • Model number: 38640
  • Serial number: 280000001 - 280999999
  • Product Type: Snowthrowers

Tire Chain Kit (Part number 107-3813)
Snow Cab (Part number 107-3814)
Weight Kit (Required with Snow Cab) (Part number 107-3815)
28" Drift Breaker (Part number 107-3817)
Toro 2-Stage Cover (Part number 490-7466)
Plain 2-Stage Cover (Part number 490-7467)

  • Model number
    38640
  • Serial number
    280000001 - 280999999
  • Product Name
    Power Max 1028 LXE Snowthrower
  • Product Brand
    Toro
  • Product Type
    Snowthrowers
  • Product Series
    Snowthrower, Two Stage Power Max
  • Chassis Type
    Two Stage
  • Swath
    28 inch
  • Discharge
    Two Stage
  • Engine/Motor Manufacturer
    Tecumseh
  • Engine/Motor Size
    358cc
  • Engine/Motor Type
    4 Cycle CARB3, EPA2
  • Engine Starter
    Electric/Recoil
  • Transmission Type
    Friction Disc
  • Traction Type
    2wd

  • Drive System: Gearbox Lubricant
    4.5 oz. (133ml) SAE 90 GL5 or higher
  • Engine: Engine Oil Type
    26 oz. (.8l) 5w-30 or 10w / API SH or higher
  • Engine: Ignition Coil Air Gap
    .012" / .3mm
  • Engine: Spark Plug
    Champion RJ19LM
  • Engine: Spark Plug Gap
    .030"/ .76mm
  • Engine: Engine Speed
    3300±150 RPM
  • Chassis: Tire Pressure
    17-20 PSI / 116-137 kPa
  • Drive System: Ground Speed
    Fwd. .7 / 1.1 / 1.5 / 1.9 / 2.3 / 2.7 Rev. 1.0 / 1.6 mph
