Série 5000, éjection arrière, 183 cm (72 po), 19,5 kW (26,5 cv), EFI, 747 cm³
Informations produit
- Numéro de modèle : 72922
- Numéro de série : 418000000 - 419999999
- Type de produit : Riding Products
Chargement...
Schémas d'assemblage
Rechercher une pièce dans des schémas d'assemblage :
-
Manuel d'entretien
-
Manuel de l'utilisateur
-
Catalogue de pièces
-
Garantie produit
-
Instructions d'installation
-
Guide du logiciel
Hitch Kit (Réf. 109-9487)
Hypr-Oil™ 500 (quart) (Réf. 114-4713)
High Performance Hydro Oil
Hypr-Oil™ 500 (gallon) (Réf. 114-4714)
High Performance Hydro Oil
HYPR-OIL 500-5 GALLON (Réf. 114-4715)
BIMINI FOLDING SHADE ASM (Réf. 115-4510)
KIT,FRPS LIGHT (Réf. 116-1154)
Seat Cover w/Arm Rest (Réf. 117-0095)
Toro OEM Seat Cover W/Arm Rest will fit Z Masters. Make your old seat look like new! Plus, the extra padding offers a more comfortable ride.
Suspension Seat and Mount Kit (Réf. 121-7596)
Toro suspension seat increases operator comfort and boosts productivity in ways you’ve never imagined. Mow longer without stopping and cut around even the most intricate landscaping at faster speeds with better results. When it comes to reliability, Toro delivers replacement parts designed to the exact engineering specifications of our equipment. For peace of mind, insist on Toro genuine parts.
SKID-BUMPER, DECK (Réf. 126-0854)
KIT-ROPS LOCK TORO (Réf. 126-4064)
Jack Kit With Adapter, Zero-Turn-Radius Side-Discharge or Rear-Dischar (Réf. 126-7282)
Jack Kit Adapter, Zero-Turn-Radius Side-Discharge or Rear-Discharge Ri (Réf. 126-7283)
Z-Master Anti-scalp & Wear Bar Kit (Réf. 127-6650)
Toro OEM anti-scalp deck wheels and wear bar. These wheels help prevent the deck from coming in contact with the ground when passing over a high spot, thus preventing the blade from slicing off or "scalping" large clumps of grass.
Riding Mower Jack Kit (Réf. 127-6666)
Genuine Toro jack mount kit. Mounts to the front of the mower and allows the owner to raise the mower to gain access to the underside of the deck to check blades or wash the deck. To best protect your investment and maintain optimal performance of your turf equipment, count on Toro genuine parts. When it comes to reliability, Toro delivers replacement parts designed to the exact engineering specifications of our equipment. For peace of mind, insist on Toro genuine parts.
Power Deck Lift Kit (Réf. 132-5986)
Easily Raise and Lower your Z-Master cutting deck with the push of a button using this Toro power lift kit. Toro operator controlled discharge kit. When it comes to reliability, Toro delivers replacement parts designed to the exact engineering specifications of our equipment. For peace of mind, insist on Toro genuine parts.
Worklight Kit (Réf. 135-7320)
Trimmer Mount Kit (Réf. 137-9769)
Toro OEM trimmer mount kit. Keep your trimmer securely mounted on your riding mower. When it comes to reliability, Toro delivers replacement parts designed to the exact engineering specifications of our equipment. For peace of mind, insist on Toro genuine parts.
24.50 Inch Atomic Blade (Réf. 140-1239)
Toro OEM 24.5 Inch Atomic blade. The Toro Atomic blade is commonly referenced as a “Gator Style” or “Gator Blade”. Provides the best quality of cut while mulching. This Toro blade has multiple applications. Be sure to verify model and serial number to ensure the correct part.
24.50 Inch Low Flow Blade (Réf. 140-1245)
Toro 24.5 Inch OEM Low Flow blade. Low Flow mower blades have slightly curved ends that keep air Flow to a minimum. The lack of suction allows cut grass to exit the mower while keeping dust and debris levels down. Toro Low Flow mower blades cause less engine strain than Hi-Flow blades. This Toro blade has multiple applications. Be sure to verify model and serial number to ensure the correct part.
Atomic 24.5 Inch Blade Pack (6) (Réf. 140-4875)
Toro OEM Atomic blade pack. (6) 24.5 Inch Atomic blades. Atomic blade is commonly referenced as a “Gator Style” or “Gator Blade”. Provides the best quality of cut while mulching. This Toro blade has multiple applications. Be sure to verify model and serial number to ensure the correct part.
Riding Mower Toe board Weights (Réf. 140-4958)
Toro genuine riding mower weight kit. Provides added stability on uneven terrain or when using rear mounted bagging attachments. When it comes to reliability, Toro delivers replacement parts designed to the exact engineering specifications of our equipment. For peace of mind, insist on Toro genuine parts.
Slope Sensor-Lazer/Z-Master 3000/5000/6000 (Réf. 142-4910)
SCREEN-SPARK ARRESTOR (Réf. 142-7683)
Jack Mount Kit (Réf. 146-0696)
MICHELIN® X® TWEEL® Turf Airless Caster Wheels (13") (Réf. 147-6295)
The MICHELIN® X® TWEEL® Turf Caster Wheel is the next “revolution” in commercial mowing. The MICHELIN X TWEEL Turf Caster Wheel has all the qualities you would want in a pneumatic tire but it never needs air. No more flats, downtime, patch kits or replacement tires. And in the area of wear and tear, this “tire” has a wear life that is three times that of a pneumatic.
TORO RIDER OVER SEAT BAG (Réf. 490-7317)
Housse de luxe Toro Titan (Réf. 490-7319)
La housse de luxe pour autoportée Toro OEM protège votre tondeuse autoportée Titan contre les éléments lorsqu'elle n'est pas utilisée. La housse est faite pour résister à l'usure et aux déchirures et possède un cordon élastique pour maintenir la housse en place. Idéale pour les équipements qui restent à l'extérieur ou pour le remisage saisonnier. Pour assurer une excellente fiabilité, Toro fournit des pièces de rechange conçues en fonction des spécifications techniques exactes de votre machine. Pour votre tranquillité d'esprit, exigez des pièces Toro d'origine.
Toro Rider Arm Rest Bag (Réf. 490-7320)
Toro genuine rider arm rest bag. When it comes to reliability, Toro delivers replacement parts designed to the exact engineering specifications of our equipment. For peace of mind, insist on Toro genuine parts.
Toro Filter Gauge for Kohler Engines (Réf. 99-4664)
Toro genuine filter gauge. This Toro filter gauge shows when filters are nearing restriction limits, graduated indicators help you maximize filter life and effectively schedule service intervals. Toro would like to remind you that fitment can vary by sub model, serial number, and/or production date of your equipment. Please refer to the original owners manual in order to verify this is correct part for your machine.
KIT, TRASH HOLDER (Réf. TC26)
-
Numéro de modèle
72922 -
Numéro de série
418000000 - 419999999 -
Nom du produit
Série 5000, éjection arrière, 183 cm (72 po), 19,5 kW (26,5 cv), EFI, 747 cm³ -
Marque du produit
Toro -
Type de produit
Riding Products -
Série de produit
Zero Radius Turn, Professional 5000 Series -
Type de Châssis
ZRT - LCE -
Largeur de travail
72in/183cm -
Éjection
Rear Discharge -
Fabricant du moteur
Kohler -
Taille de moteur
747cc -
Type de moteur
4 Cycle -
Démarreur
Electric -
Type de transmission
Hydrostatic -
Type de Traction
Rear WD
-
Engine: Battery
12V 300CCA -
Engine: Spark Plug Gap
.030"/ .76mm -
Chassis: Tire Pressure
13 psi / 90 kPa -
Engine: Engine Oil Type
61 oz. (1.8 Liter) SAE 10W-30 or 10W-40 -
Engine: Spark Plug
Champion XC12YC -
Chassis: Height of Cut Range
1" - 5.5" (25-140mm) -
Drive System: Ground Speed
0-10 mph / 0-16kph -
Drive System: Gearbox Lubricant
HYPR-OIL 500 / 15w-50 Synthetic Motor Oil -
Engine: Ignition Coil Air Gap
0.011in (0.3mm) -
Engine: Engine Speed
3750+/-50 RPM
