TimeCutter SS 5000 Riding Mower
Product Information
- Model #: 74731
- Serial #: 401400000 - 402334374
- Product Type: Riding Products
Loading...
Assembly Drawings
Search for a part within assembly drawings:
-
Operator's Manual
-
Parts Catalog
-
Product Warranty
-
Setup Instructions
Arm Rest Kit, 2006 400, 500 Series w/Dark Grey Seat (Part # 110-5719)
Deck Ring Kit, 50in Mowers for Zero-Turn-Radius Riding Mower (Part # 114-1608)
Hourmeter Kit, 2011 and After Zero-Turn-Radius Riding Mower (Part # 116-5461)
OIL - SYNTHETIC, ALL SEASON (Part # 117-0066)
SEAT COVER W/O ARM REST - TC 18IN (Part # 117-0096)
Striping Kit, 42in and 50in Mowers (Part # 120-7905)
Jack Mount Kit (Part # 126-5251)
Jack Kit, Zero-Turn-Radius Side-Discharge or Rear-Discharge Riding Mow (Part # 127-6666)
Fuel Stabilizer .05 oz (Part # 130-2393)
4-CYCLE FUEL, SNOW AND LAWN, 32OZ CAN (Part # 131-3823)
Attachment Mount Kit, Zero-Turn-Radius Riding Mower (Part # 131-3966)
Toro Premium Fuel Treatment (Part # 131-6572)
Weight Kit, Zero-Turn-Radius Riding Mower (Part # 131-7658)
Deluxe Seat Kit, Zero-Turn-Radius Riding Mower (Part # 131-7699)
Maintenance Kit - Toro V-Twin Engine (Part # 132-4878)
Floor Mat Kit, Lever Steering Zero-Turn-Radius Riding Mower (Part # 132-6921)
MAINTENANCE KIT TORO V-TWIN HD ENGINE (Part # 136-7847)
HD Air Cleaner Kit (Part # 136-7860)
Pro-control Damper Kit (Part # 138-7588)
10W30 4-CYCLE ENGINE OIL 32 OZ BOTTLE (Part # 38280)
TORO 4-CYCLE SAE 30 OIL (32OZ BOTTLE) (Part # 38903)
COVER (Part # 490-7516)
Foot Assist Deck Lift Kit, 2011 and After Zero-Turn-Radius Riding Mowe (Part # 79010)
Sunshade Kit, 2011 and After Zero-Turn-Radius Riding Mower (Part # 79011)
BLADE KIT - TIMECUTTER 50IN (Part # 79016P)
50in Recycler Kit, 2007 and After Riding Mower (Part # 79019)
Assist Handle and Step Kit, Riding Mower (Part # 79339)
TimeCutter SS & SW 50 in. / 54 in. Twin Bagger (Part # 79392)
The Toro TimeCutter Twin Bagger with its 6.43 bushel (8 cu. ft.) capacity makes quick work of taking care of grass clippings or fallen leaves. When paired with one of Toro's top discharge decks, its performance can't be beat. It assembles easily and once initially installed, can be removed and put back on without tools. Includes bagger, mount kit and front weights.
-
Model #
74731 -
Serial #
401400000 - 402334374 -
Product Name
TimeCutter SS 5000 Riding Mower -
Product Brand
Toro -
Product Type
Riding Products -
Product Series
Zero Radius Turn, Consumer -
Chassis Type
ZRT - Consumer -
Swath
50 inch -
Discharge
Side -
Engine/Motor Manufacturer
Toro -
Engine/Motor Size
24.5 hp -
Engine/Motor Type
4 Cycle -
Engine Starter
Electric -
Transmission Type
Hydrostatic -
Traction Type
Rear WD
-
Engine: Battery
12V 195CCA -
Engine: Spark Plug Gap
.030"/ .76mm -
Chassis: Tire Pressure
13 psi / 90 kPa -
Chassis: Height of Cut Range
1.5-4.5"; 1/2" increments -
Engine: Engine Speed
3300±100 RPM -
Drive System: Ground Speed
Fwd. 0 - 7.0 Rev. 0 - 3.5 mph -
Engine: Ignition Coil Air Gap
0.011in (0.3mm) -
Engine: Spark Plug
Champion RN9YC / NGK BPR6ES -
Engine: Engine Oil Type
2.5 qts (80 oz. or 2.4L) 10W-30 with filter change -
Drive System: Gearbox Lubricant
HYPR-OIL 500 / 20w-50 Synthetic Motor Oil
