522 Power Throw Snowthrower

Product Information

  • Model number: 38605
  • Serial number: 270000001 - 270004504
  • Product Type: Snowthrowers

Drift Breaker 22" (Part number 37-7022)
Toro 2-Stage Cover (Part number 490-7466)
Plain 2-Stage Cover (Part number 490-7467)
Tire Chain Kit (Part number 56-2700)
Snow Cab (Part number 88-0600)

  • Model number
    38605
  • Serial number
    270000001 - 270004504
  • Product Name
    522 Power Throw Snowthrower
  • Product Brand
    Toro
  • Product Type
    Snowthrowers
  • Product Series
    Snowthrower, Two Stage Small Frame
  • Chassis Type
    Two Stage
  • Swath
    22 inch
  • Discharge
    Two Stage
  • Engine/Motor Manufacturer
    Tecumseh
  • Engine/Motor Size
    195cc
  • Engine/Motor Type
    4 Cycle CARB2, EPA2
  • Engine Starter
    Electric/Recoil
  • Transmission Type
    Friction Disc

  • Drive System: Ground Speed
    Fwd. .9 / 1.3 / 1.9 Rev. 1.3 mph
  • Engine: Engine Oil Type
    21 oz. (.62l) 5w-30 or 10w / API SH or higher
  • Engine: Ignition Coil Air Gap
    .012" / .3mm
  • Engine: Spark Plug
    Champion RJ19LM
  • Engine: Spark Plug Gap
    .030"/ .76mm
  • Engine: Engine Speed
    3300±150 RPM
  • Chassis: Tire Pressure
    12-15 PSI (82-102 kPa)
  • Drive System: Gearbox Lubricant
    Auger 5 oz. Lubriplate Mag 1 grease
