Workman HDX-Auto Utility Vehicle
Product Information
- Model #: 07390
- Serial #: 401420001 - 403430000
- Product Type: Vehicles
Loading...
Assembly Drawings
Search for a part within assembly drawings:
-
Service Manual
-
Operator's Manual
-
Parts Catalog
-
Schematic Drawing - Electrical
-
Schematic Drawing - Hydraulic
-
Service Bulletin
Full Area Flatbed, Heavy-Duty Workman Utility Vehicle (Part # 07301)
Full Area Flatbed Side Kit, Workman (Part # 07302)
Fold Down Side Kit, Workman (Part # 07303)
2/3 Area Flatbed, Workman Heavy Duty Utility Vehicle (Part # 07321)
2/3 Area Flatbed Side Kit, Workman (Part # 07322)
Plastic Bedliner (Part # 07331)
- A rugged, weatherproof plastic construction liner that protects the cargo bed.
1/3 Area Flatbed, Workman Heavy-Duty Utility Vehicle (Part # 07341)
1/3 Area Platform Lift, Workman Heavy-Duty Utility Vehicle (Part # 07347)
Cab Heater (Part # 07349)
- Mounted inside on the passenger side near the floor
- Heater provides enhanced comfort when needed on cold weather days – ties into radiator
Canopy (Part # 07372)
- Protects operators and passengers from the sun and rain.
- Made of durable, high density polyethylene material with drainage outlets for moisture runoff.
Folding Windshield (Part # 07373)
- Clear, high impact modified acrylic material
- Quick and easy fold down design to allow air flow and enhance operator and passenger comfort.
4-Post ROPS (Part # 07378)
- Consists of four vertical posts connected together by top members.
- Protects operator from injury in case of roll over.
4-Wheel Drive Kit, Workman HDX-Auto Utility Vehicle (Part # 07391)
Cab Kit (Part # 07392)
- Features a vented front glass windshield for cross ventilation, glass windshield, and side panels for enhanced visibility, interior dome light, and a 2-speed windshield wiper.
- ROPS & CE certified
Cab Door Kit (Part # 07393)
Provide extra protection from the elements with a sleek design.
High Range Lockout Kit, 2015 and after Workman HDX-Auto Utility Vehicl (Part # 07394)
High-Flow Hydraulics Kit, Workman HDX-Auto Utility Vehicle (Part # 07395)
Hand Throttle (Part # 07420)
- Mechanical throttle and speed limit control
- Provides constant RPM for stationary attachments or a controlled maximum speed for applications such as spraying or spreading.
ATV / Snow Tires (Part # 07422)
- Aggressive tread to provide extra traction during snowy conditions.
Toro 55 Gallon Premium All-Season Hydraulic Fluid (Part # 108-1177)
Toro 55 Gallon Premium All-Season Hydraulic Fluid. Designed for use in Toro equipment created by Toro engineers. If you are unsure of your equipment needs, do a model extreme serial number search to verify that this is the correct oil type for your equipment.
Toro 5 Gallon Premium All Season Hydraulic Fluid (Part # 108-1178)
Toro 5 Gallon Premium All Season Hydraulic Fluid. Designed for use in Toro equipment created by Toro engineers. If you are unsure of your equipment needs, do a model extreme serial number search to verify that this is the correct oil type for your equipment.
Premium Trans/Hyd Tractor Fluid Drum (Part # 108-1183)
Premium Trans/Hyd Tractor Fluid Pail (Part # 108-1184)
Toro 14 oz. All-Purpose Grease (Part # 108-1190)
Toro 14 oz. All-Purpose Grease. Designed for use in Toro equipment created by Toro engineers. If you are unsure of your equipment needs, do a model extreme serial number search to verify that this is the correct oil type for your equipment.
PREMIUM ALL SEASON GEAR LUBE QUART (Part # 108-1590)
FILTER-OIL (Part # 108-3847)
Remote Hydraulics Manifold Kit (Part # 110-2626)
Remote control option for operator convenience.
Rear Tire (Part # 110-5132)
Wheel (Part # 114-8260)
Side Mirror Kit (Part # 115-7849)
Operator and passenger side mounted rear view mirrors
for enhancing all around visibility. Externally mounted to the cab frame.
ROPS Signal Kit (Part # 117-4825)
Increase safety with a ROPS signal kit.
Worklight Kit (Part # 117-4827)
Provide extra light to everyday operations.
Remote Hydraulic Float Kit (Part # 117-4828)
Receiver Hitch Kit (Part # 117-4831)
Increase towing capabilities with a receiver hitch kit.
Trailer Signal Kit (Part # 117-4836)
Increase safety with a trailer signal kit.
Manual 4-Wheel Drive Control Kit, Workman HDX/HDX-D Utility Vehicle (Part # 119-0817)
Canopy for Four-Post Roll-Over Protection System Kit (Part # 119-9457)
Increase safety on slopes with ROPS.
Road Light and Homologation Kit (Part # 120-5030)
Provide extra light to everyday operations.
Brake and Signal Light Kit, Workman HD Utility Vehicle (Part # 120-5045)
Toro 55 Gallon Premium Engine Oil 10W-30 (Part # 121-6392)
Toro 55 Gallon Premium Engine Oil 10W-30. Designed for use in Toro equipment created by Toro engineers. If you are unsure of your equipment needs, do a model extreme serial number search to verify that this is the correct oil type for your equipment.
Toro 5 Gallon Premium Engine Oil 10W-30 (Part # 121-6393)
Toro 5 Gallon Premium Engine Oil 10W-30. Designed for use in Toro equipment created by Toro engineers. If you are unsure of your equipment needs, do a model extreme serial number search to verify that this is the correct oil type for your equipment.
Trailer Brake Kit (Part # 125-0123)
Backup Alarm Kit (Part # 127-8729)
1/3 Area Cover Kit (Part # 127-8739)
High Air Intake Kit, Workman HDX-Auto Utility Vehicle (Part # 127-8740)
Exterior Mirror Kit (Part # 130-5448)
Operator and passenger side mounted rear view mirrors
for enhancing all around visibility. Externally mounted to the cab frame.
Interior Mirror Kit (Part # 130-5449)
See more and drive safer.
Beacon Kit (Part # 130-5484)
Mounts to top of cab or ROPS.
Work Lights Kit (Part # 130-5485)
Washer Fluid Kit (Part # 130-5615)
Refill your windshield wiper fluid and keep everything working.
MVP KIT 400 FILTER KIT WORKMAN HDX AU (Part # 131-8276)
Tire (Part # 131-8432)
LED Work Light Kit (Part # 133-0554)
Provide extra light to everyday operations.
Alternator Kit, Workman HDX-Auto Utility Vehicle (Part # 133-0575)
ROPS Beacon Kit (Part # 133-0609)
Mounts to top of ROPS.
Canopy Bracket Light (Part # 133-0627)
A502 Tire (Part # 136-6308)
K502 Tire (Part # 136-6309)
A404 Tire (Part # 136-6334)
A404 Tire (Part # 136-6335)
200 Gallon Multi Pro® WM Turf Sprayer (Part # 41240)
The Multi Pro WM spray system for Toro’s Workman® HD Series utility vehicles leverages the advanced spray system capability of Toro’s Multi Pro line and combines functionality with cutting-edge and intuitive sprayer controls. The result is the most advanced, efficient and accurate 200-gallon bed-mounted sprayer accessory for a utility vehicle on the market. Aggressive agitation, faster response times, consistent and accurate application rates, and intuitive rate set up, makes this the sprayer that has it all.
Spreader Base Unit, 2002 and later Workman 3000 and 4000 Series (Part # 41253)
VICON SPREADER (Part # 41256)
18 cu.ft. Top Dresser 1800 (Part # 44225)
The 18 cubic foot (.5 cu. m.) capacity Top Dresser 1800 mounts to a Toro Workman or other utility vehicle and delivers a precise, productive performance with up to 8 mph (12.9 km/h) topdressing speed. A remote on-off application lever allows precise control/placement from the comfort of the operator's compartment.
Core Harvester Adapter (Part # 44242)
Pro Force Debris Blower (Part # 44552)
Pro Force Debris Blower (Part # 44553)
Pro Force Debris Blower (Part # 44554)
21 cu.ft. ProPass™ 200 Series Top Dresser (Part # 44701)
The Toro ProPass™ 200 broadcast style top dresser delivers extremely accurate spread patterns from ultra-light dustings to ultra-heavy aeration hole filling applications without any guesswork. A wireless controller provides the easiest method to set and control the spread functions. Available in both a utility vehicle mounted version and a towed version.
Series Models:
- ProPass 200 - Bed Mounted or Tow Behind
- ProPass 200 - Bed Mounted or Tow Behind with Wireless Controller
21 cu.ft. ProPass™ 200 Series Top Dresser (Part # 44751)
The Toro ProPass™ 200 broadcast style top dresser delivers extremely accurate spread patterns from ultra-light dustings to ultra-heavy aeration hole filling applications without any guesswork. A wireless controller provides the easiest method to set and control the spread functions. Available in both a utility vehicle mounted version and a towed version.
Series Models:
- ProPass 200 - Bed Mounted or Tow Behind
- ProPass 200 - Bed Mounted or Tow Behind with Wireless Controller
Wheel Weight Kit (Part # 81115)
Genuine OEM Part
Automatic Tailgate Release Kit (Part # 92-1220)
Fuse Block (Part # 92-2641)
Lift Kit (Part # 92-4452)
Customize your ride for your needs.
Spark Arrestor Screen (Part # 94-8157)
Tire-Rear (Part # 98-2993)
23 x 10.5 - 12 4-Ply Sawtooth Tire (Part # 99-1091)
Toro 23 x 10.5 - 12 4-Ply OEM Sawtooth Tire. Toro OEM replacement pneumatic tire. This tire delivers superior traction on turf, grass & pavement. Ideal replacement tire for your riding equipment.
-
