Professional 4000 Series MyRIDE® Petrol Z Master® 122 cm 74048TE
Product Information
- Model number: 74048TE
- Serial number: 411435568 - 412599999
- Product Type: Riding Products
Loading...
Assembly Drawings
Search for a part within assembly drawings:
-
Service Manual
-
Operator's Manual
-
Parts Catalogue
-
Product Warranty
-
Setup Instructions
-
EU/UK Declaration of Conformity
Road Lights Kit (Part number 02936)
Anti-Scalp Kit, LH 400 and 500 Series w/TF Decks (Part number 108-4140)
HYPR-OIL 500 -QUART (Part number 114-4713)
HYPR-OIL 500-GALLON (Part number 114-4714)
HYPR-OIL 500-5 GALLON (Part number 114-4715)
Jack Kit With Adapter, Zero-Turn-Radius Side-Discharge or Rear-Dischar (Part number 126-7282)
Jack Kit Adapter, Zero-Turn-Radius Side-Discharge or Rear-Discharge Ri (Part number 126-7283)
Striper Kit (Part number 126-7882)
Jack Kit, Zero-Turn-Radius Side-Discharge or Rear-Discharge Riding Mow (Part number 127-6666)
Single Side Mirror Kit (Part number 134-8275)
RECYCLER KIT-G3/GRANDSTAND 48 (Part number 139-6650)
BLADE-16.50 HIGH FLOW (Part number 140-1243)
BLADE-16.50 MEDIUM FLOW (Part number 140-4860)
BLADE-16.50 LOW FLOW (Part number 140-4861)
BLADE-16.50 ATOMIC (Part number 140-4862)
BLADE-16.50 RECYCLER (Part number 140-4863)
6 PACK-BLADE, 16.5 HIGH FLOW (Part number 140-4887)
6 PACK-BLADE, 16.5 MED FLOW (Part number 140-4888)
6 PACK-BLADE, 16.5 LOW FLOW (Part number 140-4889)
6 PACK-BLADE, 16.5 ATOMIC (Part number 140-4890)
6 PACK-BLADE, 16.5 RECYCLER (Part number 140-4891)
Front Light Kit - 4000 Series (Part number 144-0389)
This Toro OEM LED light kit is designed to extend your working day by providing reliable illumination during low-light mowing conditions. Verify your model and serial number to confirm compatibility before ordering.
4000 Series Electric Deck Lift Kit (Part number 144-0390)
This genuine Toro OEM replacement part is manufactured to the exact engineering specifications of your Toro equipment, ensuring correct fit and reliable performance. Verify your model and serial number to confirm compatibility before ordering.
TRIMMER MOUNT (Part number 144-2665)
KIT, JACK MOUNT (Part number 144-2676)
48" CHUTE GATE KIT [4000] (Part number 144-2688)
ASM-VOODOO TRAC 24X9.5-12 [OS -1.41] (Part number 144-6988)
48 CE COMPLIANCE KIT [4000] (Part number 145-1261)
HANDLE EXTENSION KIT (Part number 145-3615)
6 PACK-BLADE, 16.50 HIGH FLOW (Part number 147-6254)
KIT-ELEC DECK LIFT (Part number 147-7867)
Fuel Pickup with Screen, Kit (Part number 161-6806)
Z 4000 BAGGER KIT (Part number 78463)
Z 4000 48IN COMPLETION KIT (Part number 78464)
-
Model number
74048TE -
Serial number
411435568 - 412599999 -
Product Name
Professional 4000 Series MyRIDE® Petrol Z Master® 122 cm 74048TE -
Product Brand
Toro -
Product Type
Riding Products -
Product Series
Zero Radius Turn, Commercial 4000 Series -
Chassis Type
ZRT - LCE -
Swath
48 inch / 122 cm -
Discharge
Side Discharge -
Engine/Motor Manufacturer
Kawasaki -
Engine/Motor Size
22 hp -
Engine/Motor Type
4 Cycle -
Engine Starter
Electric -
Transmission Type
Hydrostatic -
Traction Type
Rear WD
-
Engine: Battery
12V 300CCA -
Engine: Engine Speed
3100±100 RPM -
Engine: Spark Plug
NGK BPR4ES -
Engine: Spark Plug Gap
.030"/ .76mm -
Chassis: Tire Pressure
13 psi / 90 kPa -
Engine: Engine Oil Type
67 oz. (2.1 Liter) SAE 10W-30 or 10W-40 -
Drive System: Ground Speed
0-10 mph / 0-16kph -
Chassis: Height of Cut Range
1.5" - 5.5" (38-140mm) -
Engine: Ignition Coil Air Gap
0.011in (0.3mm) -
Drive System: Gearbox Lubricant
HYPR-OIL 500 / 20w-50 Synthetic Motor Oil
