50 in. (127 cm) TimeCutter® Zero Turn Mower
50 in. (127 cm) TimeCutter® Zero Turn Mower
Product Information
- Model #: 75750
- Serial #: 409479951 - 410219308
- Product Type: Riding Products
Search for a part within assembly drawings:
Showing Results
| Drawing Title | Part Number | Description |
|---|---|---|
| Title |
Model #
75750
Serial #
409479951 - 410219308
Product Name
50 in. (127 cm) TimeCutter® Zero Turn Mower
Product Brand
Toro
Product Type
Riding Products
Product Series
Zero Radius Turn, Consumer
Chassis Type
ZRT - Consumer
Swath
50 inch
Discharge
Side Discharge
Engine/Motor Manufacturer
Kawasaki
Engine/Motor Size
726cc
Engine/Motor Type
4 Cycle
Engine Starter
Electric
Transmission Type
Hydrostatic
Traction Type
2wd
Engine: Spark Plug
NGK BPR4ES
Engine: Spark Plug Gap
.030"/ .76mm
Chassis: Tire Pressure
13 psi / 90 kPa
Chassis: Height of Cut Range
1.5-4.5"; 1/2" increments
Engine: Engine Speed
3300±100 RPM
Engine: Battery
12V 230CCA
Engine: Ignition Coil Air Gap
0.011in (0.3mm)
Drive System: Ground Speed
Forward: 0-7 mph
Engine: Engine Oil Type
71 oz. (2.1L) 10w-30 with filter change
Drive System: Gearbox Lubricant
HYPR-OIL 500 / 20w-50 Synthetic Motor Oil
