TITAN MX6080 Zero-Turn-Radius Riding Mower
TITAN MX6080 Zero-Turn-Radius Riding Mower
Product Information
- Model #: 74873
- Serial #: 313000001 - 313999999
- Product Type: Riding Products
Search for a part within assembly drawings:
Showing Results
| Drawing Title | Part Number | Description |
|---|---|---|
| Title |
Model #
74873
Serial #
313000001 - 313999999
Product Name
TITAN MX6080 Zero-Turn-Radius Riding Mower
Product Brand
Toro
Product Type
Riding Products
Product Series
Zero Radius Turn, Consumer
Chassis Type
ZRT - Consumer
Swath
60 inch
Discharge
Side Discharge
Engine/Motor Manufacturer
Kawasaki
Engine/Motor Size
24 hp
Engine/Motor Type
4 Cycle
Engine Starter
Electric
Transmission Type
Hydrostatic
Traction Type
Rear WD
Engine: Battery
12V 195CCA
Engine: Engine Speed
3600±100 RPM
Engine: Spark Plug
NGK BPR4ES
Engine: Spark Plug Gap
.030"/ .76mm
Chassis: Height of Cut Range
1.5-4.5"; 1/4" increments
Engine: Ignition Coil Air Gap
.008-.016" / .2-.4mm
Engine: Engine Oil Type
67 oz. (2.1 Liter) SAE 10W-30 or 10W-40
Drive System: Ground Speed
Fwd. 0 - 7.5 Rev. 0 - 3.8 mph
Drive System: Gearbox Lubricant
HYPR-OIL 500 / 15w-50 Synthetic Motor Oil
Chassis: Tire Pressure
Rear 13 psi; Front See Sidewall of Tire
