Lawnmower
Lawnmower
Product Information
- Model #: 16785
- Serial #: 8000001 - 8007011
- Product Type: Walk Behind Mowers
Search for a part within assembly drawings:
Loading...
Showing Results
| Drawing Title | Part Number | Description |
|---|---|---|
| Title |
Operator's Manual
Service Manual
Parts Catalog
Model #
16785
Serial #
8000001 - 8007011
Product Name
Lawnmower
Product Brand
Toro
Product Type
Walk Behind Mowers
Product Series
21" Side Discharge
Chassis Type
Cast Deck WPM
Swath
21 inch
Discharge
Side
Engine/Motor Manufacturer
Suzuki
Engine/Motor Type
2 Cycle
Engine Starter
Recoil
Transmission Type
Gear
Drive System: Ground Speed
3.26 mph
Chassis: Height of Cut Range
1-3"; 1/2" increments
Drive System: Gearbox Lubricant
3 oz. (90ml) SAE 90 GL5 or higher
Engine: Engine Oil Type
Toro 2 cycle / NMMA-TCW3
Engine: Engine Speed
3000±150 RPM
Engine: Ignition Coil Air Gap
.015-.020" / .4-.5mm
Engine: Mix Ratio
50:1 (2.6 oz./gal.)
Engine: Spark Plug
NGK BPMR6A
Engine: Spark Plug Gap
.032"/ .8mm
