22in Recycler Lawn Mower
22in Recycler Lawn Mower
Product Information
- Model #: 20074
- Serial #: 270000001 - 270999999
- Product Type: Walk Behind Mowers
Search for a part within assembly drawings:
Loading...
Showing Results
| Drawing Title | Part Number | Description |
|---|---|---|
| Title |
Operator's Manual
Service Manual
Parts Catalog
Model #
20074
Serial #
270000001 - 270999999
Product Name
22in Recycler Lawn Mower
Product Brand
Toro
Product Type
Walk Behind Mowers
Product Series
22" Steel Deck
Chassis Type
Steel Deck WPM
Swath
22 inch
Discharge
Recycler & Rear Bagger
Engine/Motor Manufacturer
Tecumseh
Engine/Motor Size
195cc
Engine/Motor Type
4 Cycle CARB3 2006, EPA2
Engine Starter
Electric/Recoil
Transmission Type
Gear
Traction Type
Rear WD
Engine: Engine Speed
2900±150 RPM
Engine: Spark Plug
Champion RJ19LM
Engine: Spark Plug Gap
.030"/ .76mm
Chassis: Height of Cut Range
1.25-4.25", 3/8" increments
Drive System: Ground Speed
0-4.8 mph
Engine: Engine Oil Type
20 oz. (.6l) 30w / API SH or higher
Engine: Battery
12V
