TRX-250 Walk-Behind Trencher (22983)

  • Model: 22983
  • UPC/EAN: 21038229836
Find a Dealer
  • Low center of gravity and large footprint, offer stability and increased maneuverability
  • Exclusive Intelli-Trench™ Technology
  • Fewer parts than previous models simplifies maintenance

Overview

Toro TRX walk-behind trenchers are now more efficient and powerful than ever. We’ve improved our lineup with two new models that combine the groundbreaking maneuverability the TRX walk-behind trencher is known for with even better performance and serviceability.

Features

White male wearing a ball cap and blue shirt operating TRX-250.
Track Design
The track drive design provides a low center of gravity and large footprint, offering stability and increased maneuverability without causing damage to existing turf.
Control system for the TRX 250.
Easy-to-Use Controls
The TRX’s streamlined controls are easy to learn and operate. Designed to include the familiar TRX trencher valve handle and boom lift lever, as well as independent traction control for the left track and the right track.
White male operating TRX-300 wearing a long sleeve white shirt with a ball cap.
Exclusive Intelli-Trench® Technology
Intelli-Trench automatically diverts the hydraulic flow from the traction motors to the trencher motor when needed, delivering higher torque while reducing trenching times. Track speed is also adjusted faster and more accurately, eliminating the need for constant manual adjustment of the traction controls.
Boom Motion
Boom Motion
The boom lift and lower function has been enhanced hydraulically, allowing the boom to move up and down smoothly.
Simplified Service
Simplified Service
The new TRX design has significantly fewer parts than previous models, simplifying maintenance and potentially reducing service needs.

Specifications

Boom Depth Options (cm) 60.9 cm, 91.4 cm and 121.9 cm
Boom Depth Options (inches) 24", 36" and 48"
Boom Width Options (cm) 10.1 cm and 15.2 cm
Boom Width Options (inches) 4" and 6"
Cooling System Air Cooled
Engine Make Toro
Engine Model V-Twin
Fuel Tank (gallons) 4
Fuel Tank (liters) 15.1
Fuel Type Gasoline
Ground Pressure 24" (60.9 cm) boom = 4.1 psi 36" (91.4 cm) boom = 4.4 psi 48" (121.9 cm) boom = 4.5 psi
Ground Speed Forward (mph) 2.4
Ground Speed Foward (km/h) 3.9
Ground Speed Reverse (km/h) 2.4
Ground Speed Reverse (mph) 1.2
Headshaft Speed 210 rpm with 498 ft/lbs of torque
Hour Meter Standard
Hydraulic Flow Auxiliary 13.2 gpm (50.0 lpm)
Hydraulic Flow Traction 16.2 gpm (61.3 lpm) transport 30 gpm (11.4 lpm) trenching (each pump)
Hydraulic Oil Cooler Standard
Hydraulic Pressure (bar) 184
Hydraulic Pressure (psi) 2670
Manufacturer's Gross HP Rating 24.5
Manufacturer's Gross kW Rating 18.3
Oil Capacity (liters) 2.4
Oil Capacity (quarts) 2.5
Overall Height (cm) 116.8
Overall Height (inches) 46
Overall Length w/24" Boom (inches) 82.5
Overall Length w/61 cm Boom (cm) 209.5
Overall Width (cm) 86
Overall Width (inches) 33.8
Reservoir Capacity (gallons) 6.3
Reservoir Capacity (liters) 23.8
RPM 3600
Start Method Electric
Track Drive Sprocket-drive, 3 road wheels per side
Track Width (cm) 14.9
Track Width (inches) 5.9
Tracks Endless nylon reinforced rubber
Traction Two-section hydraulic pump with two hydraulic motors (one for each track)
Weight (kg) 500
Weight (lbs) 1104
Wheelbase (cm) 58.4
Wheelbase (inches) 23

Documents

Title Documents
TRX Trenchers Sell Sheet PDF - Sellsheet-en-us
Walk-Behind Trenchers Brochure PDF - Brochure-en-us

Parts & Manuals

Select your model year from the options below to view parts & manuals.

22983 Serial #
415300000-999999999
413000000-415299999
411800000-412999999
410480000-411799999
407960000-410479999
407740000-407959999
405700000-407739999
400000000-405699999



Warranty

For complete product warranty information contact Toro Customer Service

**See dealer for Warranty details.
