5000 Series Rear Discharge 60 in. (152 cm) 25 hp EFI 747cc

With Michelin® X® Tweel® Turf Tires
  • Model: 72921
  • UPC/EAN: 21038729213
See All Items in Z Master® 5000 Series
  • Tweel Turf Tires - No air pressure to maintain, no flat tires, no compromises. Extra long wear life two to three times that of a pneumatic tire at equal tread depth.
  • Our TURBO FORCE deck features heat-treated steel blades and our patented adjustable discharge chute, nothing cuts as fast or as well
  • Deluxe suspension seat features thick cushions, large bolsters, fully adjustable to match operator comfort
  • Unitized pump and wheel motor uses proven commercial hydraulic components while eliminating hoses and other potential leak points
  • Horizon360® Business Management Software. Work More Efficiently. Run More Profitably.

Expert Setup & Delivery

Ground Shipping Only

Overview

Z Master Professional 5000 Series mowers offer rear discharge decks for increased productivity in taller grass. These EFI models also use up to 25% less fuel than equivalent non-EFI mowers. The rear discharge design allows operators to trim on either side of the deck — no need to change direction to avoid discharging debris on roadways, sidewalks or flowerbeds. Clippings are dropped within the path of the mower, saving time and cleanup.

Features

Michelin® X® Tweel® Turf Tires
Michelin® X® Tweel® Turf Tires
No air pressure to maintain, no flat tires, no compromises. Get extra long wear life two to three times that of a pneumatic tire at equal tread depth.
Exclusive TURBO FORCE Deck
Exclusive TURBO FORCE Deck
High-capacity TURBO FORCE decks deliver unsurpassed strength, a superior cut, and increased productivity in extreme mowing conditions. Equipped with a patented adjustable baffle, TURBO FORCE decks can be fine-tuned in order to conquer changing turf conditions.
7-Gauge, High-Strength Steel
7-Gauge, High-Strength Steel
The TURBO FORCE deck is constructed of 7-gauge, high-strength steel which is 33% thicker and 32% higher in yield strength than ordinary 10-gauge commercial steel used in 7/10 decks. The combined effect is 75% stronger, so it easily handles the most demanding conditions and resists damage from impacts and abrasion.
A Flat Crisp Cut with Precision Blades
A Flat Crisp Cut with Precision Blades
(.250) thick precision blades resist flexing to provide a flat, crisp cut. High-strength, heat-treated alloy steel survives impacts and provides resistance to the rapid wear commonly associated with abrasive conditions. Options include Recycler® and Atomic® mulching blades, medium sail Bahai blades, and low sail sand blades.
Deluxe Suspension Seat
Deluxe Suspension Seat
Deluxe suspension seat features thick cushions, large bolsters and 3-D isolator mounts that absorb bumps and vibrations to reduce operator fatigue.
Smarter design in a bull-nose bumper.
Smarter design in a bull-nose bumper
7-gauge bull-nose bumper not only protects against frontal impacts, but also contains an integral underskirt to minimize blowout of debris and dust. The bottom, leading edge of the deck is raised 1/4" (6 mm), allowing grass to stand more upright when entering the cutting chamber, ensuring a level cut. Leaf "plowing" during spring and fall clean-up also is significantly reduced.
Patented Adjustable Baffle
Patented Adjustable Baffle
Allows operator to achieve maximum cutting performance by fine-tuning deck to conquer changing conditions, unique job sites or different times of the season. In extreme conditions, the baffle can be opened in order to conserve power and achieve faster mowing speeds. In less demanding conditions, the baffle can be closed to yield micro-sized particles and maximize discharge velocity.
Smooth, Powerful Response
Smooth, Powerful Response
The new unitized pump and wheel motor use proven commercial hydraulic components while eliminating hoses and other potential leak points. You'll get a smoother, faster response while enjoying an even more reliable machine.
Operator Information Center
Operator Information Center
The instrument panel includes a digital hour meter, fuel gauge, and voltage meter, as well as diagnostic indicators for the safety interlock system.
Folding Rollover Protection System ROPS
Folding Rollover Protection System ROPS
A Rollover Protection System (ROPS), complete with seat belt, comes standard for operator protection in the case of accidental rollovers and tipovers. In situations where sufficient vertical clearance is not available, such as loading on an enclosed trailer, the ROPS can be temporarily unlocked and folded down.
Cast Aluminum Spindle
Cast Aluminum Spindle
Cools quickly for enhanced durability and performance.
Horizon360 system used by contractor
Horizon360® Business Management Software.
Managing and growing your business is hard work. Using a business management software system shouldn't make it harder. That is why we built Horizon360. If you can type and point/click a mouse, you have all the skills required.

For more information click here.

Specifications

Adjustable Discharge Baffle Standard
Air Filter Heavy-Duty Canister Air Cleaner
Anti Scalp Wheels 2 Side Bumpers, 4 Rollers
Armrests Standard
Blade Tip Speed 18,500 ft/min / 5,638 m/min
Blades 0.204 in. (0.5 cm) heat-treated steel
Box Dimensions 91 in. x 70 in. x 52 in. / 231.1 cm x 177.8 cm x 132.1 cm
CARB Compliant CARB Compliant
Carrier Frame 3 in. x 1.5 in. x 10 gauge (7.6 cm x 3.8 cm x 10 gauge)
Caster Tires 13 in. x 6.5 in. - 6 in. (33 cm x 16.5 cm - 15.2 cm) Flat-Free Semi-Pneumatic
Clutch Electromagnetic
Comfort Platform Deluxe Suspension with 3-D Isolation Mounts
Cup Holder Standard
Deck Design 80-Grade 7-gauge 60" (152.4 cm) TURBO FORCE® Rear Discharge w/ bull-nose bumper
Deck Size 60 in / 152 cm
Discharge Chute Rubber
Drive System Unitized Pumps 12cc and Wheel Motors 14.6 cir
Drive Tires Airless radial 24 in. (60.9 cm) Michelin x Tweel Turf Tires
Engine 26.5 hp* (20kW) Kohler® Command Pro EFI 747 cc
Engine Brand Kohler
Engine Displacement (cc) 747 cc
Engine Horsepower 25 hp
Forward Ground/Transport Speed Up to 10.0 mph / 16.0 kph
Front Bumper Reinforced Bull-Nose
Fuel Capacity 12 gal. / 45.4 L / 48 Qt.
Fuel Type Gasoline
Height of Cut 1.0 - 5.5 in. / 2.5 - 14.0 cm
Hour Meter Standard
Hydraulic Fluid Premium synthetic
Ignition Electric
Number of Blades 3
Product Features Electric Start, Gas Powered, Hour Meter
Product Type Zero Turn Mowers
Product Use Commercial
Roll-Over Protection System (ROPS) Folding; Standard
Seat Handcrafted Deluxe Suspension Seat with Arm Rests Featuring Bullhorn Accent
Spindle Bearings Greaseless Ball Bearings
Spindle Housing 9 in / 22.9 cm Diameter Cast Aluminum
Start Type Electric
Steering Controls 1-5/8" (4.1 cm) Diameter Grips; Adjustable, Dampened
Weight 1,324 lbs / 600.6 kg

Disclaimer

*The gross horsepower of these engines was laboratory rated by the engine manufacturer in accordance with SAE J1940 or SAE J2723. As configured to meet safety, emission and operating requirements, the actual engine horsepower on these mowers will be significantly lower.

Accessories

Empty Image Container
Hypr-Oil™ 500 (quart)
Hypr-Oil™ 500 (quart) (Part # 114-4713)
Hypr-Oil™ 500 (gallon)
Hypr-Oil™ 500 (gallon) (Part # 114-4714)
Genuine OEM Part 114-4715
Hypr-Oil™ 500 Hydraulic Oil (5 gallon) (Part # 114-4715)
Bimini Folding Sunshade Assembly
Bimini Folding Sunshade Assembly (Part # 115-4510)
Empty Image Container
Toro Genuine Parts Logo
Seat Cover w/Arm Rest (Part # 117-0095)
Genuine OEM Part 117-3600
Operator-Controlled Discharge Chute Kit (Part # 117-3600)
Genuine OEM Part 121-7596
Suspension Seat and Mount Kit (Part # 121-7596)
Empty Image Container
Empty Image Container
Genuine OEM Part 127-6650
Z-Master Anti-scalp & Wear Bar Kit (Part # 127-6650)
Genuine OEM Part 127-6665
Riding Mower Jack Mount Kit (Part # 127-6665)
Riding Mower Jack Kit
Riding Mower Jack Kit (Part # 127-6666)
Please contact your local dealer
Genuine OEM Part 132-5986
Power Deck Lift Kit (Part # 132-5986)
Please contact your local dealer
Empty Image Container
Empty Image Container
Trimmer Mount Kit (Part # 137-9769)
24" Tweel Tire
MICHELIN® X® TWEEL® Turf Airless Radial Tires (24") (Part # 139-7891)
Genuine OEM Part 140-1241
20.5 Inch Atomic Blade (Part # 140-1241)
Genuine OEM Part 140-1244
20.50 Inch Low Flow Blade (Part # 140-1244)
Please contact your local dealer
Genuine OEM Part 140-1241
Atomic 20.5 Inch Blade Pack (6) (Part # 140-4880)
Genuine OEM Part 140-4958
Riding Mower Toe board Weights (Part # 140-4958)
Genuine OEM Part 144-0379
Z-Master 60 Inch Deck Baffle Kit (Part # 144-0379)
Genuine OEM Part 490-7319
Toro Titan Deluxe Cover (Part # 490-7319)
Please contact your local dealer
Empty Image Container
Toro Rider Arm Rest Bag (Part # 490-7320)
Empty Image Container
Image Not Found
5000 SERIES 60IN DECK TF RD AUSTRALIA (Part # 78970)
Toro Genuine Parts Logo
Toro Filter Gauge for Kohler Engines (Part # 99-4664)
Empty Image Container

Documents

Title Documents
Z Master 5000 Rear Discharge Sellsheet PDF - Sellsheet-en-us

Parts & Manuals

Select your model year from the options below to view parts & manuals.



Warranty

5-Year / 1200 Hours

**See dealer for Warranty details.
