60 in. (152 cm) TimeCutter® Max Zero Turn Mower
Model: 77601
60 in. (152 cm) TimeCutter® Max Zero Turn Mower
Model: 77601
Model: 77601 UPC/EAN: 21038776019
Key Features
- Over 100 years of Pro DNA course through the veins of every mower we build.
- Its heavy duty steel IronForged® Deck doesn't flinch no matter what you throw its way.
- The gaming-style seat gives you big time support exactly where you need it.
- The four-point deck hanging system doesn't flinch under your feet when you get on or off the mower.
Financing Available
Free Shipping
-
Ground Shipping Only
-
Cannot ship to the following states: AK, HI
Resources
Product Details
Proven by Pros. Perfected for You.
Turf Tough. Bull Strong.
Comfort. Game On.
Sturdy Step-On.
Traction for Any Terrain.
Better Fill. Fewer Spills.
Shut Down Sprayback.
Compatible with the MyToro App
For more information click here.
Air Filter
Standard Kawasaki Air Cleaner
Anti Scalp Wheels
3 Standard
Armrests
Optional Accessory - Not Included
Assembled Depth
80 in / 203.2 cm
Assembled Height
45.5 in / 115.6 cm
Assembled Width
71.5 in / 181.6 cm
Bagger Capacity
4.9 bushels
Bagger Included
Optional Accessory - Not Included
Blade Tip Speed
18,500 ft/min / 5,638 m/min
Box Dimensions
82.0 in. x 63.0 in. x 35.0 in. / 208.3 cm x 160.0 cm x 88.9 cm
CARB Compliant
Not CARB Compliant
Carrier Frame
3 in. x 1.5 in. x 0.120 in. (7.6 cm x 3.8 cm x 0.3 cm) Wall Tubular Steel
Caster Tires
13 in. x 6.5 in. - 6 in. (33 x 16.5 cm - 15.2 cm) Pneumatic
Clutch
Electromagnetic
Comfort Platform
Standard Suspension
Cooling System
Air Cooled
Crankshaft
1" (25 mm) w/Steel Protector
Cup Holder
Standard
Cutter System
Steel Cutting Blade
Deck Design
10-Gauge steel IrongForged®
Deck Material
10 Gauge Steel
Deck Size
60 in / 152 cm
Discharge Chute
Side
Drive System
Hydrostatic
Drive Tires
20 in. x 10 in. - 8 in (51 cm x 26 cm - 20.3 cm)
Drive Type
Rear-Wheel Drive
Engine
23 hp Kawasaki FR691V 726cc
Engine Brand
Kawasaki
Engine Displacement (cc)
726 cc
Engine Horsepower
23.0 hp
Engine Power (kW)
17.2 kW
Foot Operated Height of Cut
Standard
Forward Ground/Transport Speed
Up to 7.0 mph / 11.2 kph
Forward Mowing Speed
Up to 7.0 mph / 11.2 kph
Frame
3 in. x 1.5 in. (7.6 cm x 3.8 cm) Steel Tubing
Fuel Capacity
5 gal. / 18.9 L / 20 Qt.
Fuel Type
Gasoline
Greasable Bearings
Yes
Height of Cut
1.0 - 5.0 in. / 2.5 - 12.7 cm
Hitch Bracket
Standard
Hour Meter
Standard
Hydraulic Drive
Standard
Lighting
Optional
Number of Blades
3
Product Type
TimeCutter Max
Product Use
Residential
Recommended Oil Type
10W-30
Roll-Over Protection System (ROPS)
Optional
Seat
19" Gaming Style
Spindle Bearings
Maintenance-free
Spindle Housing
Cast-Aluminum
Start Type
Electric
Steering Controls
Twin Lever
Steering Dampeners
Standard Dampers
Terrain Type
Flat with Obstacles
Tires
13 in. x 6.5 in. (33 cm x 16.5 cm) Front, 20 in. x 11 in. (50.8 cm x 27.9 cm) Rear
Transmission
Dual Hydrostatic HG-ZT2800
Washout Port
Standard
Weight
668 lbs / 303 kg
Disclaimer
†See retailer for complete warranty details.
‡Specifications subject to change without notice and without incurring obligation. Products depicted are for demonstration purposes only. Actual products offered for sale may vary in design, required attachments and safety features.
- 2026 Toro TimeCutter Zero Turn Mower Sell Sheet.pdf PDF - Sellsheet-en-us
- 2026 Zero Turn Mowers Accessory Guide.pdf PDF - Accessories-en-us
3-Year Residential Limited Warranty
**See dealer for Warranty details.
