Groundsmaster 220
Product Information
- Model #: 30620
- Serial #: 790001 - 799999
- Product Type: Riding Products
Loading...
-
Service Manual
-
Operator's Manual
-
Service Bulletin
WEIGHT-REAR (Part # 24-5790)
WEIGHT-REAR [RED] (Part # 24-5790-01)
TIRE CHAINS (1 PAIR) (Part # 28-5470)
52 Inch Blower Kit (Part # 30502)
62" Blower Kit, Mower (Part # 30503)
9.0 cu. ft. Bagger Kit (Part # 30504)
52" Side Discharge Mower (Part # 30652)
62" Side Discharge Mower (Part # 30662)
Mulcher Kit, 52" Mower (Part # 30700)
Deluxe Seat Kit (Part # 30705)
Leaf Mulcher 62" (Part # 30792)
18.00 Inch High Sail/Flow Blade (Part # 44-5480)
Toro 18.00 Inch OEM High Sail/Flow blade. This Sharp replacement blade provides a crisp, clean cut time after time. You can count on the reliability of this Toro replacement High Sail/Flow rotary mower blade. This Toro blade has multiple applications. Be sure to verify model and serial number to ensure the correct part.
Debris Blower 2670 (Part # 44524)
Debris Blower Adapter Kit (Part # 44529)
XRef: 56-2390-03 (Part # 56-2390)
18 Inch Mower Blade (Part # 56-2390-03)
Toro 18 Inch OEM Hi Flow blade. Hi-Flow are also known as basic blades, regular blades, or 2-in-1 blades, Hi-Flow mower blades are the go-to blades for mowers with a bagger. The blades are designed to cut the grass and Flow the clippings, propelling them up and out of the discharge chute. This Toro blade has multiple applications. Be sure to verify model and serial number to ensure the correct part.
LOW COST MULCHER (Part # 57-0700)
52"DECK RECYCLER KIT (Part # 59225)
*OBS* 52" FRONT BAFFLE KIT (Part # 68-7210)
High Sail Blade (Part # 77-6710)
62" FRONT BAFFLE KIT (Part # 82-8800)
-
Model #
30620 -
Serial #
790001 - 799999 -
Product Name
Groundsmaster 220 -
Product Brand
Toro -
Product Type
Riding Products -
Product Series
Groundsmaster 62" / 200 Series -
Swath
Deck Optional -
Discharge
Deck Optional -
Engine/Motor Manufacturer
Onan -
Engine/Motor Size
20 hp -
Engine/Motor Type
4 Cycle CARB1 -
Engine Starter
Electric -
Transmission Type
Hydrostatic
-
Engine: Spark Plug
Champion RS14YC -
Engine: Spark Plug Gap
.025"/ .64mm -
Engine: Engine Speed
3200±100 RPM -
Chassis: Tire Pressure
10-15 psi -
Engine: Engine Oil Type
1.8 qt (1.7L) 10w-30 engine oil API SF or higher -
Drive System: Gearbox Lubricant
5 qts. 10w-30 engine oil API SF or higher
