TimeCutter Z4200 Riding Mower
Product Information
- Model #: 74380
- Serial #: 270000001 - 270999999
- Product Type: Riding Products
Loading...
Assembly Drawings
Search for a part within assembly drawings:
-
Service Manual
-
Operator's Manual
-
Parts Catalog
-
EU Declaration of Conformity
-
Setup Instructions
Smooth Front Tires Kit (Part # 110-6739)
Genuine OEM Part
Hour Meter Kit (Part # 112-9763)
Keep track of mowing hours and planned maintenance with the Toro Hour Meter Kit. Ffits on select models of TimeCutter SS and SW zero turn mowers.
TimeCutter 42" Bagging Enhancement Kit (Part # 114-1620)
Get that pristine lawn you’ve been dreaming of with the help of the Toro’s Leaf Bagging Enhancement and make short work of it. Decreases leaf blowout on the deck when bagging leaves and increases bagging performance. Fits select models of TimeCutter SS and SW zero turn mowers.
21.6 Inch Replacement Blade Kit for 42 Inch TimeCutter (2007 - 2017) - 2 pack (Part # 131-3939-03P)
Replacement Blade Kit contains two 21.6 in. Hi-Flow blades for your Toro 42 in. TimeCutter. The blade stiffener that is included on 2007-2014 models must be removed prior to installing these blades. See instruction sheet for details. Using genuine Toro mower blades produces a crisp cut and promotes a healthy lawn.
Please contact your local dealer
Engine Cover Kit (Part # 79314)
Genuine OEM Part
Please contact your local dealer
Please contact your local dealer
Please contact your local dealer
42in and 50in Twin Bagger, TimeCutter MZ Series Riding Mower (Part # 79324)
-
Model #
74380 -
Serial #
270000001 - 270999999 -
Product Name
TimeCutter Z4200 Riding Mower -
Product Brand
Toro -
Product Type
Riding Products -
Product Series
Zero Radius Turn, Consumer -
Chassis Type
ZRT - Consumer -
Swath
42 inch -
Discharge
Side -
Engine/Motor Manufacturer
Kohler -
Engine/Motor Size
19 hp -
Engine/Motor Type
4 Cycle EPA2 -
Engine Starter
Electric -
Transmission Type
Hydrostatic
-
Chassis: Tire Pressure
Front 35 PSI / 2.5kg sq. cm, Rear 13 PSI / .9kg sq. cm -
Engine: Ignition Coil Air Gap
.010" / .25mm -
Engine: Spark Plug Gap
.030"/ .76mm -
Drive System: Ground Speed
Fwd. 0 - 5.5 Rev. 0 - 2.3 mph -
Engine: Battery
12V -
Chassis: Height of Cut Range
1.5-4.5"; 1/2" increments -
Engine: Spark Plug
Champion XC12YC -
Engine: Engine Oil Type
1.6 qts 10w-30 -
Engine: Engine Speed
2650±100 RPM
