Dingo® TX 1000 Wide Track

Model: 22328
UPC/EAN: 21038223285

Find a Dealer

Class-leading rated operating capacity with 1,000 rated operating capacity
Maximum height and reach easily clears the side of a 30-yard dumpster
Compact footprint fits through standard 36" gates

Top

Find a Dealer

Overview

Designed with vertical lift loader arms, its 1,000-lb. rated operating capacity delivers category-crushing performance that’s an industry game-changer. The Dingo TX 1000 also offers increased reach at full height for maximum jobsite productivity. And speaking of productivity, an 81" (206 cm) hinge pin height allows the arms to clear the side of a 30-yard dumpster or one-ton truck. This lightweight, maneuverable machine packs unmatched strength and reach in a compact package for the ultimate working advantage.

Features

Class-Leading Rated Operating Capacity

Vertical lift loader arms allow the Dingo TX 1000 to lift and transport heavy loads with a rated operating capacity of 1,000-plus pounds.

Maximum Height & Reach

The 81” (206 cm) hinge pin height allows attachments to easily clear the side of 30-yard dumpsters or one-ton trucks.

Compact Size

Narrow enough so you can bring hydraulic power to tight areas; through doorways and gates previously accessible only by manual labor. Plus it provides zero radius turn capability for unmatched maneuverability.

Specifications

Air Filter	Two-stage, heavy-duty, remote
Cooling System	Liquid Cooled
Displacement (cc)	1262
Displacement (cu. in.)	77
Dump Angle	40 degrees
Dump Height (cm)	155
Dump Height (inches)	61
Engine Make	Kubota
Engine Model	D1305
Fuel Tank (gallons)	11.5
Fuel Tank (liters)	44
Fuel Type	Diesel
Ground Clearance (cm)	15
Ground Clearance (inches)	6
Ground Pressure	3.6 psi
Ground Speed Forward (mph)	4.7
Ground Speed Foward (km/h)	7.6
Ground Speed Reverse (km/h)	7.6
Ground Speed Reverse (mph)	4.7
Hinge Pin Height (cm)	206
Hinge Pin Height (inches)	81
Hydraulic Flow Auxilary	15.2 gpm
Hydraulic Flow Traction	13.3 gpm (each pump)
Hydraulic Pressure	3000 PSI
Loader Arms	Vertical Lift
Manufacturer's Gross HP Rating (HP)	24.9
Manufacturer's Gross HP Rating (kW)	18.6
Max Operating Height (cm)	267
Max Operating Height (inches)	105
Oil Capacity (liters)	5.7
Oil Capacity (quarts)	6
Overall Height (cm)	135
Overall Height (inches)	53.2
Overall Length w/bucket (cm)	256
Overall Length w/bucket (inches)	100.7
Overall Length w/o bucket (cm)	208
Overall Length w/o bucket (inches)	81.7
Overall Width (cm)	104
Overall Width (inches)	41
Rated Operating Capacity - 35% of Tip Capacity (kg)	488
Rated Operating Capacity - 35% of Tip Capacity (lbs)	1075
Reach – Fully Raised (cm)	62
Reach – Fully Raised (inches)	24.5
Reservoir Capacity (gallons)	15.2
Reservoir Capacity (liters)	57.5
RPM	2600
Tip Capacity (kg)	1393
Tip Capacity (lbs)	3071
Track Length (inches)	127.6
Track Length(cm)	324
Track Width (cm)	24
Track Width (inches)	9.5
Tracks	Sprocket-drive, 6 road wheels per side
Traction	Dual Hydrostatic Pump
Weight (kg)	1266
Weight (lbs)	2790
Wheelbase (inches)	41

Accessories

Light Kit (Part # 144-7100)

Light kit fits: Dingo TX 1000 - LED (650 LM)

KIT ROAD WHEEL, 5-PACK (Part # 144-7392)

KIT ROAD WHEEL, 5-PACK (Part # 144-7393)

DECAL KIT - HERC (Part # 145-6943)

Standard Bucket for Dingo® TX 1000 (Part # 22340)

Use this standard bucket for moving rock, dirt, sand or other materials off and around the job site. The hardened steel cutting edge offers improved cutting and digging capability for better performance to handle tough digging conditions and affords superior wear. Capacity = 4 cubic feet (1 cu. m.).

Adjustable Forks, TX 1000 Compact Utility Loaders (Part # 22341)

High Volume Bucket for Dingo® TX 1000 (Part # 22342)

Designed for Dingo® TX 1000, volume = 9.0 cubic feet

Light Materials Bucket (Part # 22410)

Designed for moving light materials like chip-bark, mulch, snow and loam. The larger capacity bucket, 6.4 cubic feet (.2 cu. m.), is great for handling larger loads of lighter materials. The hardened steel cutting edge allows for improved cutting and digging capability for better performance to handle tough digging conditions and affords superior wear.

Utility Blade (Part # 22414)

The Toro Dingo hydraulic blade greatly increases the versatility of your Dingo system. This incredibly versatile attachment can be used for a variety of earth or snow moving jobs. Fill trenches where rows of trees have been planted or irrigation pipes have been installed. Keep your hydraulic blade working in the winter by pushing snow from sidewalks in one pass.

Bore Drive Head (Part # 22420)

The Toro® Dingo® boring unit allows you to dig under sidewalks and driveways to simplify irrigation and cable installations. Shorter rod lengths and the ability to lower the bore head below grade allow you to work in both confined and open areas, increasing your productivity.

Rod and Reamer Kit (Part # 22421)

Used with 22420 to tunnel under driveways, sidewalks, etc.

Multi-Purpose Tool (Part # 22423)

This versatile attachment is actually 3 tools in 1! Easily converts into a ripper, boom or tow-bar by simply changing a few pins. Use these tools to move, carry, lift, prep, rip, dig up, transport and haul.

Power Box Rake (Part # 22426)

The Toro Power Box Rake is the perfect tool for seed bed and sod bed preparation. The rotary drum on the power box rake pulverizes rough soil, cuts high spots and fills low spots in one pass; while removing rocks and debris. Pure carbide teeth design produces the best possible seeded sub-soil, which promote superior moisture retention and rapid seed growth.

Stump Grinder Attachment (Part # 22429)

The Toro® Dingo® Stump Grinder easily attaches to either Dingo or Dingo TX compact utility loaders. Make grinding stumps quicker and more productive with the stump grinder attachment for your Toro Dingo.

Hydraulic Tree Forks (Part # 22438)

The Toro Dingo hydraulic tree forks can help you plant trees and large shrubs quickly and effortlessly, plus move all sorts of materials around your garden center or nursery. The Dingo Compact Utility Loader is especially easy to maneuver, helping you transport and position trees or shrubs exactly where you want them.

Cement Bowl (Part # 22442)

This unique attachment will mix and pour up to 200 pounds (90.7 kg) of dry cement. The specially designed auger flighting inside the cement bowl keeps the cement in the bowl during mixing. This same auger design permits cement to be poured into fence post holes with the posts in place!

Tiller (Part # 22445)

The Toro Dingo tiller attachment greatly increases the productivity and performance of your Dingo system. Break through hard soil conditions up to 6" (15.2 cm) deep. Avoid clogging the tiller by using one easy hand control to reverse the direction of the tiller to clear jams from rocks and debris.

Trencher Crumber (Part # 22464)

Spring design, trencher accessory to help clean out trenches

Trench Filler (Part # 22472)

Designed for time and money-saving efficiency, this attachment lets operators fill trenches in a single pass. Two sets of opposing augers direct the spoils from the sides of the trench back into the hole, while the filler levels off the work area and fluffs the turf on each side of the trench minimizing its footprint

High Torque Trencher Head (Part # 22473)

High-torque trencher head with heavy-duty drive system guarantees performance in the toughest soil conditions from rock to caliche. Dig trenches up to 50" (127 cm) below grade. Heavy-duty nose roller bearing and reversible abrasion-resistant boom give you years of dependable use.

High Speed Trencher Head (Part # 22474)

Ideal for fast, efficient trenching in most soil conditions. Great for cable, pipe or irrigation installations.

4-in-1 Bucket (Part # 22478)

Designed to be used on the Dingo 323, 320-D, e-Dingo, TX 427, TX 525 and TX 1000 models, this attachment offers the versatility of 4 attachments. Use as a standard bucket, a leveler, a grapple rake and a blade.

Narrow Bucket (Part # 22520)

Handle compact construction and remodeling sites by moving through 36" (91.4 cm) gates without a problem. This 35" (88 cm) wide bucket allows you to get through narrow spaces, including gates and doorways. Move rock, dirt, sand or other materials off and around the job site. Great for use on any Dingo® model equipped with narrow wheels and tires.

Standard Bucket with Spacer (Part # 22522)

Addresses MA hoisting regulation. Results in 450 lb. rated operating capacity. Capacity = 4.3 cubic feet

Grapple Rake (Part # 22577)

The Toro grapple rake attachment allows operators to grab, drag, lift, and place materials with ease. The grapple has two heavy-duty cylinders capable of producing 3000 pounds of clamping force at the tine tips, insuring you can "grab-ahold" and not let go.

Snow Canopy for Dingo® TX 1000 (Part # 22584)

Operators will feel more secure and protected in wintry conditions with the TX 1000 snow canopy exclusively for the Dingo TX 1000 models. It shields operators from wind and snow, so they can comfortably concentrate on the task at hand.

Snow Thrower (Part # 22585)

The Toro snow thrower attachment has enough power for heavy-duty performance in wet snow condition, plus a gentle touch for lighter conditions. The maximum hydraulic flow is 15.5 gpm and the chute articulation is electrical, so the operator never needs to worry about hand cranking.

High Torque Auger Power Head (Part # 22805)

In any drive head, there is a tradeoff between torque (power) and speed (revolutions per minute). The high torque head provides a large amount of torque to the auger at a slower speed. The high torque translates into the Dingo's capability to dig 30" (76.2 cm) holes up to 6' (1.8 m) deep in clay, gravel, sandstone and many other conditions where lower torque heads get stuck.

Universal Swivel Auger (Part # 22806)

This attachment swivels in all directions to create plumb holes on uneven terrain. The higher speed of this auger power head is ideal for augers up to 24" (61cm) in diameter. Quickly change between auger bit sizes to dig holes for fence posts, footings, irrigation heads and more!

18" Auger Bit (Part # 22814)

18" auger bit requires auger power head attachment 22805 or 22806.

24" Auger Bit (Part # 22815)

24" auger bit requires auger power head attachment 22805 or 22806.

30" Auger Bit (Part # 22816)

30" auger bit requires auger power head attachment 22805.

12" Auger Extension (Part # 22818)

Add extension to any auger to increase depth.

24" Auger Extension (Part # 22819)

Add extension to any auger to increase depth.

6" Full Flight Auger Bit (Part # 22820)

6" full flight auger bit requires auger power head attachment 22805 or 22806.

9" Full Flight Auger Bit (Part # 22821)

9" full flight auger bit requires auger power head attachment 22805 or 22806.

12" Full Flight Auger Bit (Part # 22822)

12" full flight auger bit requires auger power head attachment 22805 or 22806.

15" Full Flight Auger Bit (Part # 22823)

15" full flight auger bit requires auger power head attachment 22805 or 22806.

Vibratory Plow (Part # 22911)

The Toro® Dingo® vibratory plow attachment greatly reduces a contractor's time spent on irrigation and cable installations. Exclusively designed and built by Toro specifically for use on the Dingo, the vibratory plow optimizes pipe-pulling performance while minimizing turf damage during an installation. Also, use the chuted blade and spool carrier to install wire or cable.

Soil Cultivator (Part # 23102)

The soil cultivator is the ultimate attachment for soil preparation! This incredibly versatile attachment can be used to cultivate and level soil as well as blend landscape materials, compost and fertilizer. This attachment will also bury debris such as stones, soil clods and grass. It transforms rough terrain into a perfect planting bed in one pass.

Backhoe (Part # 23106)

This powerful attachment can be used for various jobsite activities - digging foundations, planting trees, trenching for irrigation and utilities installation and much more.Requires fit-up kit model 23126

Backhoe Fit-up Kit (Part # 23126)

Allows 23106 to fit-up to Dingo TX 1000 units

Low Flow Auxiliary Kit, TX 1000 Compact Utility Loader (Part # 23134)

Concrete Breaker, Dingo Compact Utility Loaders (Part # 23135)

Leveler (Part # 23165)

This versatile and highly productive tool is a must have attachment for all job sites. Use to grade, finish, and spread landscape materials, backfill trenches, and break up the turf. Also great for carrying and trasporting materials around the job site.

Double Detent Valve (Part # 23171)

TX 1000 Stump Grinder Fit-Up Kit (Part # 23172)

Kit available for 22429 stump grinder F'16 and prior year models. Only required for TX 1000 F'15 and F'16 models.

Red Paint (Gallon) (Part # 361-11)

Genuine OEM Part

Dark Metallic Gray Paint (Part # 361-12)

Genuine OEM Part

Semi-Gloss Black Paint (Part # 361-9)

Genuine OEM Part

Red Paint (Part # 5340)

Genuine OEM Part

Spark Arrestor (Part # 98-9099)

Toro OEM spark arrestor prevents carbon build ups from being ejected from the engine and igniting a fire.

Documents

Title	Documents
DINGO® TX 1000 Sell Sheet.pdf	PDF - Sellsheet-en-us

Parts & Manuals

Select your model year from the options below to view parts & manuals.

22328 Serial #
412900000-999999999
412438203-412899999
411840000-412438202
410500000-411839999
409985647-410499999
409588176-409985646
408963400-409588175
408900000-408963399
408000000-408899999
407400000-407999999
407100000-407399999
406724948-407099999
405800000-406724947
404356214-405799999
403330000-404356213
402000000-403329999
401321135-401999999
400414000-401321134
400000000-400413999
316000200-316999999
316000001-316000199
315000001-315999999

Warranty

For complete product warranty information contact Toro Customer Service

22328 Product Warranty

**See dealer for Warranty details.
