314-8 Garden Tractor

314-8 Garden Tractor

314-8 Garden Tractor

Product Information

  • Model #: 73449
  • Serial #: 210000001 - 210999999
  • Product Type: Riding Products

Search for a part within assembly drawings:

Loading...

Showing Results

Drawing Title Part Number Description
Title
Loading...



Operator's Manual
Parts Catalog
Setup Instructions

Model #

73449

Serial #

210000001 - 210999999

Product Name

314-8 Garden Tractor

Product Brand

Toro

Product Type

Riding Products

Product Series

Garden Tractor, 3/4/500, C, GT

Swath

Deck Optional

Discharge

Deck Optional

Engine/Motor Manufacturer

Kohler

Engine/Motor Size

14 hp

Engine/Motor Type

4 Cycle CARB1, EPA1

Engine Starter

Electric

Transmission Type

Gear

Chassis: Tire Pressure

12 PSI / .5kg sq. cm

Drive System: Ground Speed

Fwd. .5 - 5.5 Rev. .7 & 2.6 mph

Engine: Battery

12V 195CCA

Engine: Engine Speed

High 3325, Low 1200 RPM

Engine: Spark Plug

Champion RC12YC

Engine: Spark Plug Gap

.040"/ 1mm
