S-620 Snowthrower
S-620 Snowthrower
Product Information
- Model #: 38162
- Serial #: 6000001 - 6999999
- Product Type: Snowthrowers
Search for a part within assembly drawings:
Loading...
Showing Results
| Drawing Title | Part Number | Description |
|---|---|---|
| Title |
Service Manual
Parts Catalog
Model #
38162
Serial #
6000001 - 6999999
Product Name
S-620 Snowthrower
Product Brand
Toro
Product Type
Snowthrowers
Product Series
Snowthrower, Single Stage, CR/S140/S200/S620
Chassis Type
Single Stage
Swath
20 inch
Discharge
Single Stage
Engine/Motor Manufacturer
Tecumseh
Engine/Motor Size
2.5 hp
Engine/Motor Type
2 Cycle
Engine Starter
Electric
Transmission Type
NA
Engine: Engine Oil Type
Toro 2 cycle / NMMA-TCW3
Engine: Engine Speed
4500±200 RPM
Engine: Ignition Coil Air Gap
.013" / .33mm
Engine: Mix Ratio
50:1 (2.6 oz./gal.) Orig. 32:1
Engine: Spark Plug
Champion RCJ8Y
Engine: Spark Plug Gap
.030"/ .76mm
