Product Information

  • Model #: 20384
  • Serial #: 312000001 - 312999999
  • Product Type: Walk Behind Mowers
21 Inch Standard Bagging Blade
21 Inch Standard Bagging Blade (Part # 108-3759-03)
Empty Image Container
Empty Image Container
Walk Power Mower (WPM) Maintenance Toro Kit (Part # 20239)
Cover for 20 to 22 Inch Walk-Behind Mowers
Cover for 20 to 22 Inch Walk-Behind Mowers (Part # 490-7462)
Please contact your local dealer
  • Model #
    20384
  • Serial #
    312000001 - 312999999
  • Product Name
    Super Recycler Lawn Mower
  • Product Brand
    Toro
  • Product Type
    Walk Behind Mowers
  • Product Series
    21" Cast Deck
  • Chassis Type
    Cast Deck WPM
  • Swath
    21 inch
  • Discharge
    Recycler & Side Discharge with Rear Bag
  • Engine/Motor Manufacturer
    Toro
  • Engine/Motor Type
    4 Cycle
  • Engine Starter
    Electric/Recoil
  • Transmission Type
    Gear
  • Traction Type
    Rear WD
  • Engine: Engine Speed
    3000±100 RPM
  • Engine: Spark Plug Gap
    .030"/ .76mm
  • Chassis: Height of Cut Range
    1.25-4.25", 1/2" increments
  • Engine: Spark Plug
    Champion RN9YC / NGK BPR6ES / NHPS F7RTC (OEM China)
  • Engine: Valve Lash (Intake)
    0.0035 - 0.0045 inch (0.08~0.12 mm)
  • Engine: Valve Lash (Exhaust)
    0.0055 - 0.0065 inch (0.13~0.17 mm)
  • Engine: Ignition Coil Air Gap
    .010-.020" / .25-.5mm
  • Engine: Engine Oil Type
    20 oz. (.59L) SAE 30 or SAE 10W-30 / API SJ or higher
