| Blade Tip Speed | 18,500 ft/min / 5,638 m/min |
|---|---|
| Box Dimensions | 91 in. x 70.25 in. x 52.5 in. / 231.1 cm x 178.4 x 133.4 cm |
| CARB Compliant | CARB Compliant |
| Caster Tires | 13 in. x 6.5 in. - 6 in. (33 cm x 16.5 cm - 15.2 cm) Pneumatic |
| Clutch | Electromagnetic |
| Deck Design | 5” (12.7 cm) deck depth, 7/10-Gauge High-Strength Steel TURBO FORCE® w/ bull-nose bumper |
| Deck Material | 7/10 Gauge High-Strength Steel |
| Deck Size | 60 in / 152 cm |
| Discharge Chute | Rubber |
| Drive Tires | Kenda K3012 23 in. x 12 in. - 12 in. (58.4 cm x 30.5 cm - 30.5 cm) |
| Engine | 23.5 hp* Kawasaki FX730V 726 cc |
| Engine Brand | Kawasaki |
| Engine Displacement (cc) | 726 cc |
| Engine Horsepower | 23.5 hp |
| Foot Operated Height of Cut | Standard |
| Forward Ground/Transport Speed | Up to 10.0 mph / 16.0 kph |
| Front Bumper | Reinforced Bull-Nose |
| Fuel Capacity | 7 gal. / 26.5 L / 28 Qt. |
| Fuel Type | Gasoline |
| Height of Cut | 1.5 - 5.0 in. / 3.8 - 12.7 cm |
| Hour Meter | Standard |
| Lighting | Optional |
| Product Features | CARB Compliant, Deluxe Seat, Electric Start, Foot Operated Height of Cut, Gas Powered |
| Product Use | Commercial |
| Roll-Over Protection (ROPS) | Folding; Standard |
| Seat | High-Back Suspension Comfort with Arm Rests |
| Spindle Bearings | Maintenance-free |
| Spindle Housing | 8 in / 20.3 cm Diameter Aluminum |
| Start Type | Electric |
| Steering Controls | 1.4" (3.6 cm) Diameter Grips; Adjustable, Dampened |
| Tool Mounting Capability | Side Console / Rear Guard Ready |
| Transmission | Hydro-Gear ZT-3400 |
Disclaimer
Select your model year from the options below to view parts & manuals.
| 77260 Serial # |
|---|
| 411437702-999999999 |
| 410200000-411437701 |
| 400000000-410199999 |
**See dealer for Warranty details.
