| Armrests | Optional Accessory - Not Included |
|---|---|
| Bagger Included | Optional Accessory - Not Included |
| Blade Design | 0.164 in. / 0.417 cm Steel with Blade Stiffner |
| Blade Engagement | Electromagnetic Clutch |
| Blade Tip Speed | 18,179 ft/min / 5,541 m/min |
| Box Dimensions | 82.0 in. x 49.0 in. x 35.0 in. / 208.3 cm x 124.5 cm x 88.9 cm |
| CARB Compliant | Not CARB Compliant |
| Caster Tires | 11 in. x 4 in. (27.9 cm x 10.2 cm) |
| Clutch | Electromagnetic |
| Controls | Dual Wrap Around Levers |
| Cooling System | Air Cooled |
| Crankshaft | 1" (25 mm) w/Steel Protector |
| Cup Holder | Standard |
| Cutter System | Steel Cutting Blade |
| Deck Design | 42" Stamped Deck |
| Deck Material | 13 Gauge Steel |
| Deck Size | 42 in / 107 cm |
| Discharge Chute | Side |
| Drive System | Hydrostatic |
| Drive Tires | 18 in. x 6 in. - 8 in. (45.7 cm x 15.2 cm - 20.3 cm) |
| Drive Type | Rear-Wheel Drive |
| Engine | 22.0 hp Toro V-Twin Engine |
| Engine Brand | Toro |
| Engine Displacement (cc) | 724 cc |
| Engine Horsepower | 22.0 hp |
| Engine Power (kW) | 16.4 kW |
| Foot Operated Height of Cut | Standard |
| Forward Ground/Transport Speed | Up to 7.0 mph / 11.2 kph |
| Forward Mowing Speed | Up to 7.0 mph / 11.2 kph |
| Fuel Capacity | 3 gal. / 11.4 L / 12 Qt. |
| Fuel Type | Gasoline |
| Height of Cut | 1.5 - 4.5 in. / 3.8 - 11.4 cm |
| Hitch Bracket | Standard |
| Hour Meter | Optional |
| Lighting | Optional |
| Number of Blades | 2 |
| Product Features | 4-Point Deck Lift System, Adjustable Control, Adjustable Cutting Height, Adjustable Seat, Cup Holder, Deck Washout Port, Electric Start, Hitch Bracket, Low Back Seat, Smart Speed, Tool-less Deck Belt Cover, Tool-less Deck Removal |
| Product Type | TimeCutter |
| Product Use | Residential |
| Recommended Oil Type | 10W-30 |
| Roll-Over Protection System (ROPS) | Optional |
| Seat | 18" Handcrafted |
| Spindle Bearings | Maintenance-free |
| Spindle Housing | Cast-Aluminum |
| Start Type | Electric |
| Steering Controls | Dual Wrap Around Levers |
| Steering Dampeners | Hydraulic Dampeners |
| Terrain Type | Flat with Obstacles |
| Tires | 11 in. x 4 in. (27.9 cm x 10.2 cm) Front, 18 in. x 7.5 in. (45.7 cm x 19 cm) Rear |
| Tow Speed | Up to 4.0 mph / 6.4 kph |
| Transmission | Dual Hydrostatic HG-ZT2100 |
| Trim Speed | Up to 5.5 mph / 8.8 kph |
| Washout Port | Standard |
| Yard Size | Up to 2 acres |
Disclaimer
Select your model year from the options below to view parts & manuals.
| 77406 Serial # |
|---|
| 400000000-999999999 |
**See dealer for Warranty details.
