Mid-Size ProLine Gear, 13 hp w/ 32" SD Mower

Image Not Found

Product Information

  • Model #: 30252
  • Serial #: 220000001 - 220999999
  • Product Type: Walk Behind Mowers

  • Model #
    30252
  • Serial #
    220000001 - 220999999
  • Product Name
    Mid-Size ProLine Gear, 13 hp w/ 32" SD Mower
  • Product Brand
    Toro
  • Product Type
    Walk Behind Mowers
  • Product Series
    Mid-Size ProLine Mower
  • Swath
    32 inch
  • Discharge
    Side
  • Engine/Motor Manufacturer
    Kohler
  • Engine/Motor Size
    13 hp
  • Engine/Motor Type
    4 Cycle CARB1, EPA1
  • Engine Starter
    Recoil
  • Transmission Type
    Gear

  • Engine: Engine Speed
    3600±100 RPM
  • Drive System: Gearbox Lubricant
    Peerless Bentonite Grease
  • Drive System: Ground Speed
    2.0 / 2.5 / 3.7 / 4.1 / 6.2 mph
  • Engine: Ignition Coil Air Gap
    015-.020"/ .38-.5mm
  • Engine: Spark Plug
    Champion RC12
  • Engine: Spark Plug Gap
    .040"/ 1.02mm
  • Chassis: Height of Cut Range
    1" - 4.5" (25-114mm)
  • Chassis: Tire Pressure
    12-14 psi rear / 25 psi front
  • Engine: Ignition Coil Air Gap
    .0078-.0118" / .2-.3mm
  • Drive System: Ground Speed
    Fwd. 2.0 / 2.5 / 3.7 / 4.1 / 6.2 Rev. 3.2 mph
  • Engine: Engine Oil Type
    64 oz. (1.9 Liter) SAE 10W-30 or 10W-40
  • Engine: Spark Plug
    Champion RC12YC or Champion Premium Gold 2071
