Mid-Size ProLine T-Bar Gear, 13 HP with 32in Side Discharge Mower

Image Not Found

Product Information

  • Model #: 30316
  • Serial #: 250000001 - 250999999
  • Product Type: Walk Behind Mowers

Genuine OEM Part 106-0820
Midsize Weight Kit (Part # 106-0820)
Empty Image Container
MS 32" SOFT BAGGER (Part # 30124)
Image Not Found
44" / 112cm Side Discharge Mower SFS Deck (Part # 30149)
Image Not Found
52" SFS Side Discharge Mower (Part # 30151)
Empty Image Container
TIRE KIT (Part # 30158)

  • Model #
    30316
  • Serial #
    250000001 - 250999999
  • Product Name
    Mid-Size ProLine T-Bar Gear, 13 HP with 32in Side Discharge Mower
  • Product Brand
    Toro
  • Product Type
    Walk Behind Mowers
  • Product Series
    Mid-Size ProLine Mower
  • Chassis Type
    Mid-size - Floating Deck
  • Swath
    32 inch
  • Discharge
    Side
  • Engine/Motor Manufacturer
    Kohler
  • Engine/Motor Size
    13 hp
  • Engine/Motor Type
    4 Cycle CARB2, EPA2
  • Engine Starter
    Recoil
  • Transmission Type
    Gear
  • Traction Type
    2wd

  • Engine: Engine Speed
    3600±100 RPM
  • Engine: Ignition Coil Air Gap
    .008-.012" / .2-.3mm
  • Drive System: Gearbox Lubricant
    Peerless Bentonite Grease
  • Engine: Spark Plug Gap
    .040"/ 1.02mm
  • Chassis: Height of Cut Range
    1" - 4.25" (25-108mm)
  • Chassis: Tire Pressure
    15 psi rear & castors
  • Drive System: Ground Speed
    Fwd. 0.9 / 2.1 / 3.4 / 4.3 / 5.0 Rev. 2.5 mph
  • Engine: Engine Oil Type
    64 oz. (1.9 Liter) SAE 10W-30 or 10W-40
  • Engine: Spark Plug
    Champion RC12YC or Champion Premium Gold 2071
