TimeCutter Z420 Riding Mower
Product Information
- Model #: 74327
- Serial #: 260000001 - 260019999
- Product Type: Riding Products
Loading...
-
Service Manual
-
Operator's Manual
-
Setup Instructions
Smooth Caster Wheel Kit (Part # 105-1856)
Genuine OEM Part
Please contact your local dealer
18x7.5-8 Tire Chain Kit (Part # 107-1738)
Genuine OEM Part
42 inch Anti-Scalp Kit (Part # 107-9134)
Genuine OEM Part
Armrest Kit (Part # 108-6163)
Genuine OEM Part
Hour Meter Kit (Part # 108-7158)
Genuine OEM Part
Ring Blowout Ring Kit (Part # 110-6509)
Genuine OEM Part
21.6 Inch Replacement Blade Kit for 42 Inch TimeCutter (2007 - 2017) - 2 pack (Part # 131-3939-03P)
Replacement Blade Kit contains two 21.6 in. Hi-Flow blades for your Toro 42 in. TimeCutter. The blade stiffener that is included on 2007-2014 models must be removed prior to installing these blades. See instruction sheet for details. Using genuine Toro mower blades produces a crisp cut and promotes a healthy lawn.
Red Paint (Gallon) (Part # 361-11)
Genuine OEM Part
Cover for TimeCutter Models (Part # 490-7516)
The Toro Z mower cover protects your investment by offering all-season protection. Toro covers are constructed of tough, waterproof, tear and abrasion-resistant 600-Denier polyester and will provide years of carefree protection for your mower. Toro covers protect against snow, sun damage, rain, dust, birds, tree sap and more. Toro covers also feature vents to minimize condensation and heat build-up and an elastic opening to ensure a snug, secure fit.
Please contact your local dealer
Red Paint (Part # 5340)
Genuine OEM Part
X-REF 106-2173 (Part # 79211)
Genuine OEM Part
42 Inch Twin Bagger (Part # 79214)
48" Snow Blade (Part # 79216)
-
Model #
74327 -
Serial #
260000001 - 260019999 -
Product Name
TimeCutter Z420 Riding Mower -
Product Brand
Toro -
Product Type
Riding Products -
Product Series
Zero Radius Turn, Consumer -
Chassis Type
ZRT - Consumer -
Swath
42 inch -
Discharge
Side -
Engine/Motor Manufacturer
Briggs & Stratton -
Engine/Motor Size
16 hp -
Engine/Motor Type
4 Cycle CARB2, EPA2 -
Engine Starter
Electric -
Transmission Type
Hydrostatic
-
Chassis: Tire Pressure
Front 35 PSI / 2.5kg sq. cm, Rear 13 PSI / .9kg sq. cm -
Engine: Battery
12V 260CCA -
Engine: Engine Speed
High 3400, Low 1550 RPM -
Engine: Spark Plug
Champion RC12YC -
Engine: Spark Plug Gap
.030"/ .76mm -
Drive System: Ground Speed
Fwd. 0 - 6 Rev. 0 - 3 mph
