| Armrests | Standard |
|---|---|
| Blade Tip Speed | 18,330 ft/min / 5,586 m/min |
| Box Dimensions | 82 in x 57 in x 35 in / 208.3cm x 144.8cm x 88.9cm |
| CARB Compliant | Not CARB Compliant |
| Caster Tires | 11" X 6" |
| Controls | Dual Wrap Around Levers |
| Cup Holder | Standard |
| Deck Design | 50" IronForged™ Fabricated Deck |
| Deck Material | 10 Gauge Steel |
| Deck Size | 50 in / 127 cm |
| Discharge Chute | Side |
| Drive Tires | 18" x 9.5" (45.7 cm x 24.1 cm) |
| Drive Type | Rear-Wheel Drive |
| Engine | 24 HP** Kohler Twin 7000 Series Pro Air Cleaner |
| Engine Brand | Kohler |
| Engine Displacement (cc) | 725 cc |
| Engine Horsepower | 24.0 hp |
| Foot Operated Height of Cut | Standard |
| Forward Ground/Transport Speed | Up to 7.0 mph / 11.2 kph |
| Forward Mowing Speed | Up to 7.0 mph / 11.2 kph |
| Fuel Capacity | 3 gal. / 11.4 L / 12 Qt. |
| Fuel Type | Gasoline |
| Height of Cut | 1.5 - 4.5 in. / 3.8 - 11.4 cm |
| Hitch Bracket | Standard |
| Hour Meter | Optional |
| Number of Blades | 3 |
| Product Features | Cup Holder, Electric Start, Foot Operated Height of Cut, High Back Seat, IronForged Deck, Smart Speed |
| Product Use | Residential |
| Recommended Oil Type | 10W-30 |
| Seat | 18" Handcrafted High Back with Arm Rests - Lever Slide |
| Start Type | Electric |
| Steering Controls | Dual Wrap Around Levers |
| Steering Dampeners | Pro-Control Dampers |
| Terrain Type | Smooth Lawn |
| Tires | 11" x 5.5" (27.9 cm x 14 cm) Front, 18" x 9.5" (45.7 cm x 24.1 cm) Rear |
| Tow Speed | Up to 4.0 mph / 6.4 kph |
| Transmission | Dual Hydrostatic HG-ZT2100 |
| Trim Speed | Up to 5.5 mph / 8.8 kph |
| Washout Port | Standard |
| Yard Size | Up to 4 acres |
Disclaimer
Select your model year from the options below to view parts & manuals.
| 75751 Serial # |
|---|
| 407400000-999999999 |
| 406957209-407399999 |
| 400000000-406957208 |
**See dealer for Warranty details.
