Dingo® TX 525 Wide Track
EU Declaration of Conformity
Schematic Drawing - Electrical
Schematic Drawing - Hydraulic
ACMA Declaration of Conformity
EU/UK Declaration of Conformity
TX Road wheel kit (Part # 106-7620)
Road Wheel Kit for TX 427 and 525 models.
Reference Guide Kit, Dingo TX Compact Utility Loaders (Part # 107-9310)
TRACK-AGGRESSIVE TREAD, WIDE (Part # 108-9749)
SPARE TIRE KIT ASM (Part # 144-0105)
KIT-TX427/525 SNOW THROWER POWER (Part # 144-2512)
Light Kit (Part # 144-7101)
Light kit fits: Dingo TX 427, TX 525 - LED (650 LM)
Adjustable Forks, TX 1000 Compact Utility Loaders (Part # 22341)
Standard Bucket (Part # 22409)
Use this standard bucket for moving rock, dirt, sand or other materials off and around the job site. The hardened steel cutting edge offers improved cutting and digging capability for better performance to handle tough digging conditions and affords superior wear. Capacity = 4 cubic feet (1 cu. m.).
Light Materials Bucket (Part # 22410)
Designed for moving light materials like chip-bark, mulch, snow and loam. The larger capacity bucket, 6.4 cubic feet (.2 cu. m.), is great for handling larger loads of lighter materials. The hardened steel cutting edge allows for improved cutting and digging capability for better performance to handle tough digging conditions and affords superior wear.
Utility Blade (Part # 22414)
The Toro Dingo hydraulic blade greatly increases the versatility of your Dingo system. This incredibly versatile attachment can be used for a variety of earth or snow moving jobs. Fill trenches where rows of trees have been planted or irrigation pipes have been installed. Keep your hydraulic blade working in the winter by pushing snow from sidewalks in one pass.
Bore Drive Head (Part # 22420)
The Toro® Dingo® boring unit allows you to dig under sidewalks and driveways to simplify irrigation and cable installations. Shorter rod lengths and the ability to lower the bore head below grade allow you to work in both confined and open areas, increasing your productivity.
Rod and Reamer Kit (Part # 22421)
Used with 22420 to tunnel under driveways, sidewalks, etc.
Multi-Purpose Tool (Part # 22423)
This versatile attachment is actually 3 tools in 1! Easily converts into a ripper, boom or tow-bar by simply changing a few pins. Use these tools to move, carry, lift, prep, rip, dig up, transport and haul.
Power Box Rake (Part # 22426)
The Toro Power Box Rake is the perfect tool for seed bed and sod bed preparation. The rotary drum on the power box rake pulverizes rough soil, cuts high spots and fills low spots in one pass; while removing rocks and debris. Pure carbide teeth design produces the best possible seeded sub-soil, which promote superior moisture retention and rapid seed growth.
Stump Grinder Attachment (Part # 22429)
The Toro® Dingo® Stump Grinder easily attaches to either Dingo or Dingo TX compact utility loaders. Make grinding stumps quicker and more productive with the stump grinder attachment for your Toro Dingo.
Hydraulic Tree Forks (Part # 22438)
The Toro Dingo hydraulic tree forks can help you plant trees and large shrubs quickly and effortlessly, plus move all sorts of materials around your garden center or nursery. The Dingo Compact Utility Loader is especially easy to maneuver, helping you transport and position trees or shrubs exactly where you want them.
Cement Bowl (Part # 22442)
This unique attachment will mix and pour up to 200 pounds (90.7 kg) of dry cement. The specially designed auger flighting inside the cement bowl keeps the cement in the bowl during mixing. This same auger design permits cement to be poured into fence post holes with the posts in place!
Tiller (Part # 22445)
The Toro Dingo tiller attachment greatly increases the productivity and performance of your Dingo system. Break through hard soil conditions up to 6" (15.2 cm) deep. Avoid clogging the tiller by using one easy hand control to reverse the direction of the tiller to clear jams from rocks and debris.
Trencher Crumber (Part # 22464)
Spring design, trencher accessory to help clean out trenches
Trench Filler (Part # 22472)
Designed for time and money-saving efficiency, this attachment lets operators fill trenches in a single pass. Two sets of opposing augers direct the spoils from the sides of the trench back into the hole, while the filler levels off the work area and fluffs the turf on each side of the trench minimizing its footprint
High Torque Trencher Head (Part # 22473)
High-torque trencher head with heavy-duty drive system guarantees performance in the toughest soil conditions from rock to caliche. Dig trenches up to 50" (127 cm) below grade. Heavy-duty nose roller bearing and reversible abrasion-resistant boom give you years of dependable use.
High Speed Trencher Head (Part # 22474)
Ideal for fast, efficient trenching in most soil conditions. Great for cable, pipe or irrigation installations.
TX Platform, Diesel-Powered TX Compact Utility Loader (Part # 22476)
4-in-1 Bucket (Part # 22478)
Designed to be used on the Dingo 323, 320-D, e-Dingo, TX 427, TX 525 and TX 1000 models, this attachment offers the versatility of 4 attachments. Use as a standard bucket, a leveler, a grapple rake and a blade.
Narrow Bucket (Part # 22520)
Handle compact construction and remodeling sites by moving through 36" (91.4 cm) gates without a problem. This 35" (88 cm) wide bucket allows you to get through narrow spaces, including gates and doorways. Move rock, dirt, sand or other materials off and around the job site. Great for use on any Dingo® model equipped with narrow wheels and tires.
Grapple Rake (Part # 22577)
The Toro grapple rake attachment allows operators to grab, drag, lift, and place materials with ease. The grapple has two heavy-duty cylinders capable of producing 3000 pounds of clamping force at the tine tips, insuring you can "grab-ahold" and not let go.
Snow Thrower (Part # 22585)
The Toro snow thrower attachment has enough power for heavy-duty performance in wet snow condition, plus a gentle touch for lighter conditions. The maximum hydraulic flow is 15.5 gpm and the chute articulation is electrical, so the operator never needs to worry about hand cranking.
High Torque Auger Power Head (Part # 22805)
In any drive head, there is a tradeoff between torque (power) and speed (revolutions per minute). The high torque head provides a large amount of torque to the auger at a slower speed. The high torque translates into the Dingo's capability to dig 30" (76.2 cm) holes up to 6' (1.8 m) deep in clay, gravel, sandstone and many other conditions where lower torque heads get stuck.
Universal Swivel Auger (Part # 22806)
This attachment swivels in all directions to create plumb holes on uneven terrain. The higher speed of this auger power head is ideal for augers up to 24" (61cm) in diameter. Quickly change between auger bit sizes to dig holes for fence posts, footings, irrigation heads and more!
18" Auger Bit (Part # 22814)
18" auger bit requires auger power head attachment 22805 or 22806.
24" Auger Bit (Part # 22815)
24" auger bit requires auger power head attachment 22805 or 22806.
30" Auger Bit (Part # 22816)
30" auger bit requires auger power head attachment 22805.
12" Auger Extension (Part # 22818)
Add extension to any auger to increase depth.
24" Auger Extension (Part # 22819)
Add extension to any auger to increase depth.
6" Full Flight Auger Bit (Part # 22820)
6" full flight auger bit requires auger power head attachment 22805 or 22806.
9" Full Flight Auger Bit (Part # 22821)
9" full flight auger bit requires auger power head attachment 22805 or 22806.
12" Full Flight Auger Bit (Part # 22822)
12" full flight auger bit requires auger power head attachment 22805 or 22806.
15" Full Flight Auger Bit (Part # 22823)
15" full flight auger bit requires auger power head attachment 22805 or 22806.
Vibratory Plow (Part # 22911)
The Toro® Dingo® vibratory plow attachment greatly reduces a contractor's time spent on irrigation and cable installations. Exclusively designed and built by Toro specifically for use on the Dingo, the vibratory plow optimizes pipe-pulling performance while minimizing turf damage during an installation. Also, use the chuted blade and spool carrier to install wire or cable.
Soil Cultivator (Part # 23102)
The soil cultivator is the ultimate attachment for soil preparation! This incredibly versatile attachment can be used to cultivate and level soil as well as blend landscape materials, compost and fertilizer. This attachment will also bury debris such as stones, soil clods and grass. It transforms rough terrain into a perfect planting bed in one pass.
Concrete Breaker, Dingo Compact Utility Loaders (Part # 23135)
Dingo TX Unit Fit-up Kit (Part # 23162)
Allows 23126 to fit to Dingo TX units 22321, 22322, 22323, 22324, 22327, and 22328.
Backhoe, Dingo Compact Utility Loader (Part # 23163)
Leveler (Part # 23165)
This versatile and highly productive tool is a must have attachment for all job sites. Use to grade, finish, and spread landscape materials, backfill trenches, and break up the turf. Also great for carrying and trasporting materials around the job site.
SCREEN-ARRESTER, SPARK (Part # 75-6880)
409360000 - 409929999
Dingo® TX 525 Wide Track
Compact Utility Loaders
