Discontinued

6000 Series 60" (152.4 cm) 29 HP 999cc w/Horizon™ Technology

Model: 72969
UPC/EAN: 21038729695

Our TURBO FORCE deck features heat-treated steel blades and our patented adjustable discharge chute, nothing cuts as fast or as well
Deluxe suspension seat features thick cushions, large bolsters and 3-D isolator mounts that absorb bumps and vibrations to reduce operator fatigue, fully adjustable to match operator comfort
Unitized pump and wheel motor uses proven commercial hydraulic components while eliminating hoses and other potential leak points

Top

Overview

Z Master® 6000 Series EFI models feature Horizon Technology, an onboard intelligence platform that improves fuel efficiency and productivity. This feature allows communication between key systems on the machine to enhance performance in a wide range of mowing conditions. This Z Master® 6000 Series mower has a 29 HP Kawasaki® FX EFI 999cc w/Horizon™ Technology Engine with 60" (152.4 cm) TURBO FORCE® deck.

Features

Exclusive TURBO FORCE Deck

High-capacity TURBO FORCE decks deliver unsurpassed strength, a superior cut, and increased productivity in extreme mowing conditions. Equipped with a patented adjustable baffle, TURBO FORCE decks can be fine-tuned in order to conquer changing turf conditions.

7-Gauge, High-Strength Steel

The TURBO FORCE deck is constructed of 7-gauge, high-strength steel which is 33% thicker and 32% higher in yield strength than ordinary 10-gauge commercial steel used in 7/10 decks. The combined effect is 75% stronger, so it easily handles the most demanding conditions and resists damage from impacts and abrasion.

Deluxe Handcrafted Seat with Arm Rests

Ultimate padding and back support with a handcrafted seat with arm rests and bullhorn logo.

A Flat Crisp Cut with Precision Blades

(.250) thick precision blades resist flexing to provide a flat, crisp cut. High-strength, heat-treated alloy steel survives impacts and provides resistance to the rapid wear commonly associated with abrasive conditions. Options include Recycler® and Atomic® mulching blades, medium sail Bahai blades, and low sail sand blades.

Rubber Discharge Chute

High performance rubber discharge chute allows for close trimming without damaging chute or landscape structures. Patented design provides exceptional clipping dispersion.

Smarter design in a bull-nose bumper

7-gauge bull-nose bumper not only protects against frontal impacts, but also contains an integral underskirt to minimize blowout of debris and dust. The bottom, leading edge of the deck is raised 1/4" (6 mm), allowing grass to stand more upright when entering the cutting chamber, ensuring a level cut. Leaf "plowing" during spring and fall clean-up also is significantly reduced.

Patented Adjustable Baffle

Allows operator to achieve maximum cutting performance by fine-tuning deck to conquer changing conditions, unique job sites or different times of the season. In extreme conditions, the baffle can be opened in order to conserve power and achieve faster mowing speeds. In less demanding conditions, the baffle can be closed to yield micro-sized particles and maximize discharge velocity.

Smooth, Powerful Response

The new unitized pump and wheel motor use proven commercial hydraulic components while eliminating hoses and other potential leak points. You'll get a smoother, faster response while enjoying an even more reliable machine.

Operator Information Center

The instrument panel includes a digital hour meter, fuel gauge, and voltage meter, as well as diagnostic indicators for the safety interlock system.

Folding Rollover Protection System ROPS

A Rollover Protection System (ROPS), complete with seat belt, comes standard for operator protection in the case of accidental rollovers and tipovers. In situations where sufficient vertical clearance is not available, such as loading on an enclosed trailer, the ROPS can be temporarily unlocked and folded down.

Cast Aluminum Spindle

Cools quickly for enhanced durability and performance.

Specifications

Adjustable Discharge Baffle	Standard, Tools-Free
Air Filter	Heavy-Duty Canister Air Cleaner
Blade Tip Speed	18,500 ft/min / 5,638 m/min
Blades	.25" (.6 cm) heat-treated steel
Box Dimensions	91.5 in x 70.5 in x 52.5 in / 232.4cm x 179.1cm x 133.4cm
CARB Compliant	Not CARB Compliant
Carrier Frame	3" x 1.5" x 10 gauge (7.6 cm x 3.8 cm x 10 gauge)
Caster Tires	13” X 6.5” – 6” (33 cm x 16.5 cm – 15.2 cm) Flat-Free Semi-Pneumatic
Clutch	Electromagnetic
Deck Design	80-Grade 7-gauge 60" (152 cm) TURBO FORCE® w/bull-nose bumper
Deck Material	7 Gauge Steel
Deck Size	60 in / 152 cm
Discharge Chute	Rubber
Drive System	Unitized Pumps 16cc and Wheel Motors 17.1 cir
Drive Tires	24" x 12" - 12" (61 x 30.5 - 30.5 cm)
Engine	29.5 HP* Kawasaki® FX850V EFI 852cc w/Horizon™ Technology Engine
Engine Brand	Kawasaki
Engine Displacement (cc)	852 cc
Engine Horsepower	29.5 hp
Forward Ground/Transport Speed	Up to 11.5 mph / 18.5 kph
Front Bumper	Reinforced Bull-Nose
Fuel Capacity	12 gal. / 45.4 L / 48 Qt.
Fuel Type	Gasoline
Height of Cut	1.0 - 5.5 in. / 2.5 - 14.0 cm
Hour Meter	Standard
Hydraulic Fluid	Premium synthetic
Roll-Over Protection System (ROPS)	Folding; Standard
Seat	Handcrafted Deluxe Suspension Seat with Arm Rests Featuring Bullhorn Accent
Spindle Bearings	Greaseless Ball Bearings
Spindle Housing	9 in / 22.9 cm Diameter Cast Aluminum
Start Type	Electric
Steering Controls	1-5/8" (4.1 cm) Diameter Grips; Adjustable, Dampened

Disclaimer

*The gross horsepower of this engine was laboratory rated at 3600 rpm by the engine manufacturer in accordance with SAE J1940 and SAE J2723. As configured to meet safety, emission, and operating requirements, the actual engine horsepower on this class of mower will be significantly lower.

Accessories

GrandStand Turbo Baffle Kit (Part # 107-1634)

$234.29 USD

GrandStand Turbo Baffle Kit. To best protect your investment and maintain optimal performance of your equipment, count on Toro genuine parts and accessories.

$234.29 USD

Z-Master Anti-Scalp Kit (Trim Side) (Part # 108-4140)

$164.99 USD

Toro OEM anti-scalp deck wheels. These wheels help prevent the deck from coming in contact with the ground when passing over a high spot, thus preventing the blade from slicing off or "scalping" large clumps of grass.

$164.99 USD

KIT,HITCH [GEN II] (Part # 109-9487)

$148.49 USD

Hypr-Oil™ 500 (quart) (Part # 114-4713)

$16.49 USD

High Performance Hydro Oil

$16.49 USD

Hypr-Oil™ 500 (gallon) (Part # 114-4714)

$63.79 USD

High Performance Hydro Oil

$63.79 USD

Hypr-Oil™ 500 Hydraulic Oil (5 gallon) (Part # 114-4715)

$285.99 USD

Maximize commercial mower performance with Hypr-Oil™ 500. Tested and approved by Toro Engineering.

$285.99 USD

Bimini Folding Sunshade Assembly (Part # 115-4510)

$465.51 USD

Toro genuine Optional fabric sun shade provides protection and comfort by shielding the operator from the elements.

$465.51 USD

Roller Striping Kit (Part # 115-7470)

$303.44 USD

Toro OEM A mower striping kit. The ultimate way to enhance the striping ability of your Z-Master. When it comes to reliability, Toro delivers replacement parts designed to the exact engineering specifications of our equipment. For peace of mind, insist on Toro genuine parts.

$303.44 USD

KIT,FRPS LIGHT (Part # 116-1154)

$571.99 USD

Seat Cover w/Arm Rest (Part # 117-0095)

$72.59 USD

Toro OEM Seat Cover W/Arm Rest will fit Z Masters. Make your old seat look like new! Plus, the extra padding offers a more comfortable ride.

$72.59 USD

Operator-Controlled Discharge Chute Kit (Part # 117-3600)

$509.29 USD

Toro operator controlled discharge kit. When it comes to reliability, Toro delivers replacement parts designed to the exact engineering specifications of our equipment. For peace of mind, insist on Toro genuine parts.

$509.29 USD

Z Stand Kit for Z Master Riding Mower with 48", 52" or 60" Deck (Part # 121-4811)

$588.49 USD

Toro OEM deck stand kit. Allows for easy under deck access at the shop or in the field. When it comes to reliability, Toro delivers replacement parts designed to the exact engineering specifications of our equipment. For peace of mind, insist on Toro genuine parts.

$588.49 USD

Suspension Seat and Mount Kit (Part # 121-7596)

$303.59 USD

Toro suspension seat increases operator comfort and boosts productivity in ways you’ve never imagined. Mow longer without stopping and cut around even the most intricate landscaping at faster speeds with better results. When it comes to reliability, Toro delivers replacement parts designed to the exact engineering specifications of our equipment. For peace of mind, insist on Toro genuine parts.

$303.59 USD

Riding Mower Jack Mount Kit (Part # 127-6665)

Genuine Toro jack mount kit. Mounts to the front of the mower and allows the owner to raise the mower to gain access to the underside of the deck to check blades or wash the deck. To best protect your investment and maintain optimal performance of your turf equipment, count on Toro genuine parts. When it comes to reliability, Toro delivers replacement parts designed to the exact engineering specifications of our equipment. For peace of mind, insist on Toro genuine parts.

Riding Mower Jack Kit (Part # 127-6666)

$151.79 USD

Power Deck Lift Kit (Part # 132-5986)

$1,178.09 USD

Easily Raise and Lower your Z-Master cutting deck with the push of a button using this Toro power lift kit. Toro operator controlled discharge kit. When it comes to reliability, Toro delivers replacement parts designed to the exact engineering specifications of our equipment. For peace of mind, insist on Toro genuine parts.

$1,178.09 USD

Please contact your local dealer

KIT-LIGHT, LAZER LED WORK (Part # 135-7320)

$604.99 USD

Titan HD Series Bucket Mount Kit (Part # 137-9216)

$130.89 USD

Toro OEM bucket mount kit. Saves you time, money, and hassle when you’re in the seat trying to get the day's cutting done. Carry a five gallon bucket for trash collection right on the mower so you always have a place to put the trash that's found on the ground.

$130.89 USD

Trimmer Mount Kit (Part # 137-9769)

$203.49 USD

Toro OEM trimmer mount kit. Keep your trimmer securely mounted on your riding mower. When it comes to reliability, Toro delivers replacement parts designed to the exact engineering specifications of our equipment. For peace of mind, insist on Toro genuine parts.

$203.49 USD

60 Inch Recycler Kit (Part # 139-6655)

$419.09 USD

The 60 in. Recycler Kit, when installed on compatible 42 in. deck Toro zero turn riding mowers, gives it the capability to mulch grass by cutting it multiple times turning it into fine clipping pieces. These are returned under the mower back into the soil to serve as natural fertilizer. When it comes to reliability, Toro delivers replacement parts designed to the exact engineering specifications of our equipment. For peace of mind, insist on Toro genuine parts.

$419.09 USD

MICHELIN® X® TWEEL® Turf Airless Radial Tires (24") (Part # 139-7891)

$930.59 USD

The MICHELIN® X® TWEEL® Turf Airless Radial Tires are the next “revolution” in commercial mowing has arrived. The MICHELIN X TWEEL Turf Airless Radial Tire has all the qualities you would want in a pneumatic tire but it never needs air. No more flats, downtime, patch kits or replacement tires. And in the area of wear and tear, this “tire” has a wear life that is three times that of a pneumatic.

$930.59 USD

20.5 Inch Hi-Flow Blade (Part # 140-1240)

$25.19 USD

Toro 20.5 Inch OEM Hi-Flow blade. This sharp replacement Hi-Flow lawn mower blade provides a crisp, clean cut time after time. You can count on the quality and reliability of this Toro replacement Hi-Flow lawn mower blade. This Toro blade has multiple applications. Be sure to verify model and serial number to ensure the correct part.

$25.19 USD

20.5 Inch Atomic Blade (Part # 140-1241)

$30.44 USD

Toro OEM Atomic blade 20.5 Inch Atomic blades. Atomic blade is commonly referenced as a “Gator Style” or “Gator Blade”. Provides the best quality of cut while mulching. This Toro blade has multiple applications. Be sure to verify make and serial number to ensure the correct part.

$30.44 USD

20.50 Inch Medium Flow Blade (Part # 140-4853)

$33.59 USD

Toro 20.5 Inch OEM Medium Flow blade. Medium Flow mower straight edge, standard discharge blade. These blades have slight upward angle on the edges. Great blades for use when horsepower is a concern. Produce medium Flow but requires less horsepower than Hi-Flow blades. This Toro blade has multiple applications. Be sure to verify model and serial number to ensure the correct part.

$33.59 USD

20.50 Inch Low Flow Blade (Part # 140-4854)

$33.59 USD

Toro 20.50 Inch OEM Low Flow blade. Low Flow mower blades have slightly curved ends that keep air Flow to a minimum. The lack of suction allows cut grass to exit the mower while keeping dust and debris levels down. Toro Low Flow mower blades cause less engine strain than Hi-Flow blades. This Toro blade has multiple applications. Be sure to verify model and serial number to ensure the correct part.

$33.59 USD

20.5 Inch Recycler Blade (Part # 140-4855)

$30.44 USD

Toro 20.5 Inch OEM Recycler blade. Recycler blades. Recycler straight edge, standard discharge blade. The blade is designed for a High quality cut and long-lasting durability. These blades are designed with “wings,” called “accelerators” that kind of act like a fan — forcing the tiny bits of grass back into the earth. This Toro blade has multiple applications. Be sure to verify make and serial number to ensure the correct part.

$30.44 USD

Hi-Flow20.5 Inch Blade Pack (6) (Part # 140-4877)

$151.19 USD

Toro 16.5 Inch OEM Hi-Flow blade pack. (6) Hi-Flow blades. This sharp replacement Hi-Flow lawn mower blade provides a crisp, clean cut time after time. You can count on the quality and reliability of this Toro replacement Hi-Flow lawn mower blade. This Toro blade has multiple applications. Be sure to verify model and serial number to ensure the correct part.

$151.19 USD

Mid Flow 20.5 Inch Blade Pack (6) (Part # 140-4878)

$201.59 USD

Toro 20.5 Inch OEM Medium Flow blade pack. (6) Medium Flow blades. Medium Flow mower straight edge, standard discharge blade. These blades have slight upward angle on the edges. Great blades for use when horsepower is a concern. Produce medium Flow but requires less horsepower than Hi-Flow blades. This Toro blade has multiple applications. Be sure to verify model and serial number to ensure the correct part.

$201.59 USD

Low Flow 20.5 Inch Blade Pack (6) (Part # 140-4879)

$201.59 USD

Toro 20.5 Inch OEM Low Flow blade pack. (6) Low Flow blades. Low Flow mower blades have slightly curved ends that keep air Flow to a minimum. The lack of suction allows cut grass to exit the mower while keeping dust and debris levels down. Toro Low Flow mower blades cause less engine strain than Hi-Flow blades. This Toro blade has multiple applications. Be sure to verify model and serial number to ensure the correct part.

$201.59 USD

Atomic 20.5 Inch Blade Pack (6) (Part # 140-4880)

$182.69 USD

Toro OEM Atomic blade pack. (6) 20.5 Inch Atomic blades. Atomic blade is commonly referenced as a “Gator Style” or “Gator Blade”. Provides the best quality of cut while mulching. This Toro blade has multiple applications. Be sure to verify model and serial number to ensure the correct part.

$182.69 USD

Recycler 20.5 Inch Blade Pack (6) (Part # 140-4881)

$182.69 USD

Toro 20.5 Inch OEM Recycler blade pack. (6) Recycler blades. Recycler straight edge, standard discharge blade. The blade is designed for a High quality cut and long-lasting durability. These blades are designed with “wings,” called “accelerators” that kind of act like a fan — forcing the tiny bits of grass back into the earth. This Toro blade has multiple applications. Be sure to verify model and serial number to ensure the correct part.

$182.69 USD

Riding Mower Toe board Weights (Part # 140-4958)

$175.99 USD

Toro genuine riding mower weight kit. Provides added stability on uneven terrain or when using rear mounted bagging attachments. When it comes to reliability, Toro delivers replacement parts designed to the exact engineering specifications of our equipment. For peace of mind, insist on Toro genuine parts.

$175.99 USD

TORO RIDER OVER SEAT BAG (Part # 490-7317)

Toro Titan Deluxe Cover (Part # 490-7319)

$159.99 USD

Toro OEM deluxe rider cover keeps your Titan riding lawn mower protected from the elements when not in use. Cover is made to withstand wear and tear and features elastic cord to keep cover in place. Perfect for equipment stored outside or for seasonal use. When it comes to reliability, Toro delivers replacement parts designed to the exact engineering specifications of our equipment. For peace of mind, insist on Toro genuine parts.

$159.99 USD

Toro Rider Arm Rest Bag (Part # 490-7320)

Toro genuine rider arm rest bag. When it comes to reliability, Toro delivers replacement parts designed to the exact engineering specifications of our equipment. For peace of mind, insist on Toro genuine parts.

Z-Master Spark Arrestor (Part # 75-6880)

$117.02 USD

Toro OEM spark arrestor prevents carbon build ups from being ejected from the engine and igniting a fire.

$117.02 USD

Blower and Drive Kit, 60in E-Z Vac for Z Master G3 Mower (Part # 78553)

60in E-Z Vac Triple Bagging System, Z Master G3 Mower (Part # 78563)

60in E-Z Vac DFS Collection System, Z Master G3 Mower (Part # 78567)

Toro Filter Gauge for Kohler Engines (Part # 99-4664)

$120.99 USD

Toro genuine filter gauge. This Toro filter gauge shows when filters are nearing restriction limits, graduated indicators help you maximize filter life and effectively schedule service intervals. Toro would like to remind you that fitment can vary by sub model, serial number, and/or production date of your equipment. Please refer to the original owners manual in order to verify this is correct part for your machine.

$120.99 USD

KIT, TRASH HOLDER (Part # TC26)

$91.29 USD

Parts & Manuals

Select your model year from the options below to view parts & manuals.

72969 Serial #
400000000-999999999

6000 Series 60" (152.4 cm) 29 HP 999cc w/Horizon™ Technology

Overview

Features

Exclusive TURBO FORCE Deck

7-Gauge, High-Strength Steel

Deluxe Handcrafted Seat with Arm Rests

A Flat Crisp Cut with Precision Blades

Rubber Discharge Chute

Smarter design in a bull-nose bumper

Patented Adjustable Baffle

Smooth, Powerful Response

Operator Information Center

Folding Rollover Protection System ROPS

Cast Aluminum Spindle

Specifications

Accessories

Blower and Drive Kit, 60in E-Z Vac for Z Master G3 Mower (Part # 78553)

60in E-Z Vac Triple Bagging System, Z Master G3 Mower (Part # 78563)

60in E-Z Vac DFS Collection System, Z Master G3 Mower (Part # 78567)

Parts & Manuals

Warranty

For complete product warranty information contact Toro Customer Service

Customer Reviews
