7000 Series Diesel 72" (183 cm) 25 HP 898cc

Model: 72274
UPC/EAN: 21038722740

Top

Overview

7000 Series zero turn mower with a high-volume 72" (183 cm) TURBO FORCE® deck. Powered by high-torque 25 hp (19 kw) Kubota® Diesel 898cc Engine, Fast ground speed of 11.2 mph (18 km/h).

Model 74267 shown.

Specifications

Adjustable Discharge Baffle	Standard, Tools-Free
Air Filter	Heavy-Duty Canister Air Filter
Anti Scalp Wheels	6 Standard
Armrests	Standard
Blade Tip Speed	18,500 ft/min / 5,638 m/min
Blades	.204" (5 mm) thick heat-treated steel
Box Dimensions	91.5 in x 80 in x 52.5 in / 232.4cm x 203.2xm x 133.4cm
CARB Compliant	Not CARB Compliant
Carrier Frame	2" x 2" x 3/16" (5.1 cm x 5.1 cm x 5 mm) steel
Caster Tires	13" x 6.5"- 6" (33 x 16.5 - 15.2 cm) flat-free semi-pneumatic
Clutch	Electromagnetic
Cooling System	Liquid Cooled
Deck Design	80-Grade 7-gauge 72" (183 cm) TURBO FORCE®
Deck Material	7 Gauge Steel
Deck Size	72 in / 183 cm
Discharge Chute	Rubber
Drive System	Hydraulic 16cc 1cu in Hydro Gear t andempumps
Drive Tires	24" x 12"-12" (61 x 30.5 - 30.5 cm)
Engine	25 HP* (19 kw) Kubota® Diesel 898cc
Engine Brand	Kubota
Engine Displacement (cc)	898 cc
Engine Horsepower	25 hp
Foot Operated Height of Cut	Standard
Forward Ground/Transport Speed	Up to 11.2 mph / 18.0 kph
Front Bumper	Reinforced Bull-Nose
Fuel Capacity	12 gal. / 45.4 L / 48 Qt.
Fuel Type	Diesel
Height of Cut	1.5 - 5.0 in. / 3.8 - 12.7 cm
Hydraulic Fluid	Premium synthetic
Product Features	Deluxe Seat, Diesel, Electric Start
Reverse Ground/Transport Speed	Up to 6.3 mph / 10.1 kph
Roll-Over Protection System (ROPS)	Folding; Standard
Seat	Handcrafted Deluxe Suspension Seat with Arm Rests Featuring Bullhorn Accent
Spindle Bearings	Greasable
Spindle Housing	9 in / 22.9 cm Diameter Cast Aluminum
Start Type	Electric
Steering Controls	1-5/8" (4.1 cm) Diameter Grips; Adjustable, Dampened
Z Stand	Optional

Disclaimer

*The gross horsepower of this engine was laboratory rated by the engine manufacturer in accordance with SAE J1940. As configured to meet safety, emission, and operating requirements, the actual engine horsepower on this class of mower will be significantly lower.

Accessories

Z-Master Deck Stand Kit with 72 Inch Turbot Force Side Discharge (Part # 105-1622)

$523.59 USD

Toro OEM Z-Master Deck Stand Kit for use with 72 Inch Turbot Force Side Discharge . Allows for easy under deck access at the shop or in the field. When it comes to reliability, Toro delivers replacement parts designed to the exact engineering specifications of our equipment. For peace of mind, insist on Toro genuine parts.

$523.59 USD

Z-Master Spark Arrestor (Part # 105-1672)

$35.19 USD

Toro OEM spark arrestor prevents carbon build ups from being ejected from the engine and igniting a fire.

$35.19 USD

Please contact your local dealer

Rubber Striping Kit (Part # 107-1630)

$483.99 USD

Toro OEM A mower striping kit. The ultimate way to enhance the striping ability of your Z-Master. When it comes to reliability, Toro delivers replacement parts designed to the exact engineering specifications of our equipment. For peace of mind, insist on Toro genuine parts.

$483.99 USD

GrandStand Turbo Baffle Kit (Part # 107-1634)

$234.29 USD

GrandStand Turbo Baffle Kit. To best protect your investment and maintain optimal performance of your equipment, count on Toro genuine parts and accessories.

$234.29 USD

Z-Master Light Kit (Part # 107-9880)

$422.39 USD

Extend your mowing day with these Toro genuine high-intensity, low amperage LED light kit. This lighting kit is built in durable cast aluminum alloy housing with stainless steel mounting hardware and wiring harness and lighted rocker switch. When it comes to reliability, Toro delivers replacement parts designed to the exact engineering specifications of our equipment. For peace of mind, insist on Toro genuine parts.

$422.39 USD

Roller Striping Kit (Part # 108-2162)

$696.29 USD

Hypr-Oil™ 500 (quart) (Part # 114-4713)

$16.49 USD

High Performance Hydro Oil

$16.49 USD

Hypr-Oil™ 500 (gallon) (Part # 114-4714)

$63.79 USD

High Performance Hydro Oil

$63.79 USD

Hypr-Oil™ 500 Hydraulic Oil (5 gallon) (Part # 114-4715)

$285.99 USD

Maximize commercial mower performance with Hypr-Oil™ 500. Tested and approved by Toro Engineering.

$285.99 USD

Bimini Folding Sunshade Assembly (Part # 115-4510)

$465.51 USD

Toro genuine Optional fabric sun shade provides protection and comfort by shielding the operator from the elements.

$465.51 USD

Seat Cover w/Arm Rest (Part # 117-0095)

$72.59 USD

Toro OEM Seat Cover W/Arm Rest will fit Z Masters. Make your old seat look like new! Plus, the extra padding offers a more comfortable ride.

$72.59 USD

24.5 Inch Mulching Blade (Part # 140-1238)

$36.74 USD

Toro 24.5 Inch OEM mulching blade for Z Master Professional 7500-D Series Riding Mower, with 96in TURBO FORCE Rear Discharge Mower. Toro mulching blades feature more curves and an increased cutting edge. The curved surface and increased cutting edge allows the blade to cut the grass and bring it into the deck where it is cut several more times before falling back onto the lawn in much smaller pieces. . This Toro blade has multiple applications. Be sure to verify model and serial number to ensure the correct part.

$36.74 USD

24.50 Inch Atomic Blade (Part # 140-1239)

$43.04 USD

Toro OEM 24.5 Inch Atomic blade. The Toro Atomic blade is commonly referenced as a “Gator Style” or “Gator Blade”. Provides the best quality of cut while mulching. This Toro blade has multiple applications. Be sure to verify model and serial number to ensure the correct part.

$43.04 USD

24.50 Inch Medium Flow Blade (Part # 140-4850)

$35.69 USD

Toro 24.5 Inch OEM Medium Flow blade. Medium Flow mower straight edge, standard discharge blade. These blades have slight upward angle on the edges. Great blades for use when horsepower is a concern. Produce medium Flow but requires less horsepower than Hi-Flow blades. This Toro blade has multiple applications. Be sure to verify model and serial number to ensure the correct part.

$35.69 USD

24.50 Inch Low Flow Blade (Part # 140-4851)

$40.94 USD

Toro 24.5 Inch OEM Low Flow blade. Low Flow mower blades have slightly curved ends that keep air Flow to a minimum. The lack of suction allows cut grass to exit the mower while keeping dust and debris levels down. Toro Low Flow mower blades cause less engine strain than Hi-Flow blades. This Toro blade has multiple applications. Be sure to verify model and serial number to ensure the correct part.

$40.94 USD

24.50 Inch Recycler Blade (Part # 140-4852)

$38.84 USD

Toro 24.5 Inch OEM Recycler blade. Recycler straight edge, standard discharge blade. The blade is designed for a High quality cut and long-lasting durability. These blades are designed with “wings,” called “accelerators” that kind of act like a fan — forcing the tiny bits of grass back into the earth. This Toro blade has multiple applications. Be sure to verify model and serial number to ensure the correct part.

$38.84 USD

Hi-Flow Blade Pack (6) (Part # 140-4872)

$220.49 USD

Toro 24.5 Inch OEM Hi-Flow blade pack. (6) Hi-Flow blades. This sharp replacement Hi-Flow lawn mower blade provides a crisp, clean cut time after time. You can count on the quality and reliability of this Toro replacement Hi-Flow lawn mower blade. This Toro blade has multiple applications. Be sure to verify model and serial number to ensure the correct part.

$220.49 USD

Mid Flow 24.5 Inch Blade Pack (6) (Part # 140-4873)

$214.19 USD

Toro 24.5 Inch OEM Medium Flow blade pack. (6) Medium Flow blades. Medium Flow mower straight edge, standard discharge blade. These blades have slight upward angle on the edges. Great blades for use when horsepower is a concern. Produce medium Flow but requires less horsepower than Hi-Flow blades. This Toro blade has multiple applications. Be sure to verify model and serial number to ensure the correct part.

$214.19 USD

Low Flow 24.5 Inch Blade Pack (6) (Part # 140-4874)

$245.69 USD

Toro 24.5 Inch OEM Low Flow blade pack. (6) Low Flow blades. Low Flow mower blades have slightly curved ends that keep air Flow to a minimum. The lack of suction allows cut grass to exit the mower while keeping dust and debris levels down. Toro Low Flow mower blades cause less engine strain than Hi-Flow blades. This Toro blade has multiple applications. Be sure to verify model and serial number to ensure the correct part.

$245.69 USD

Atomic 24.5 Inch Blade Pack (6) (Part # 140-4875)

$258.29 USD

Toro OEM Atomic blade pack. (6) 24.5 Inch Atomic blades. Atomic blade is commonly referenced as a “Gator Style” or “Gator Blade”. Provides the best quality of cut while mulching. This Toro blade has multiple applications. Be sure to verify model and serial number to ensure the correct part.

$258.29 USD

Recycler 24.5 Inch Blade Pack (6) (Part # 140-4876)

$233.09 USD

Toro 24.5 Inch OEM Recycler blade pack. (6) Recycler blades. Recycler straight edge, standard discharge blade. The blade is designed for a High quality cut and long-lasting durability. These blades are designed with “wings,” called “accelerators” that kind of act like a fan — forcing the tiny bits of grass back into the earth. This Toro blade has multiple applications. Be sure to verify model and serial number to ensure the correct part.

$233.09 USD

72 Inch Recycler Kit (Part # 140-8018)

$433.39 USD

The 72 in. Recycler Kit, when installed on compatible 42 in. deck Toro zero turn riding mowers, gives it the capability to mulch grass by cutting it multiple times turning it into fine clipping pieces. These are returned under the mower back into the soil to serve as natural fertilizer. When it comes to reliability, Toro delivers replacement parts designed to the exact engineering specifications of our equipment. For peace of mind, insist on Toro genuine parts.

$433.39 USD

Z-Master 72 inch Operator Chute Gate Kit (Part # 78522)

$565.39 USD

Toro OEM chute gate kit. Protect people and property from flying debris, keep grass out of flower beds and driveways, reducing raking, blowing and re-mowing.

$565.39 USD

Triple Bag Assembly, 72" Deck (Part # 78535)

Blower and Drive Kit, 72" Deck (Part # 78539)

72in DFS E-Z Vac Bagger, Z500 Series Z Master Mowers (Part # 78545)

Toro Filter Gauge for Kohler Engines (Part # 99-4664)

$120.99 USD

Toro genuine filter gauge. This Toro filter gauge shows when filters are nearing restriction limits, graduated indicators help you maximize filter life and effectively schedule service intervals. Toro would like to remind you that fitment can vary by sub model, serial number, and/or production date of your equipment. Please refer to the original owners manual in order to verify this is correct part for your machine.
