Z Master Professional 7000 Series Riding Mower, With 132cm TURBO FORCE Rear Discharge Mower
Product Information
- Model #: 72279TE
- Serial #: 406397919 - 406399999
- Product Type: Riding Products
Loading...
Assembly Drawings
Search for a part within assembly drawings:
-
Service Manual
-
Operator's Manual
-
Parts Catalog
-
Product Warranty
-
EU Declaration of Conformity
-
Setup Instructions
Z-Master Spark Arrestor (Part # 105-1672)
Toro OEM spark arrestor prevents carbon build ups from being ejected from the engine and igniting a fire.
Please contact your local dealer
Z-Master Light Kit (Part # 107-9880)
Extend your mowing day with these Toro genuine high-intensity, low amperage LED light kit. This lighting kit is built in durable cast aluminum alloy housing with stainless steel mounting hardware and wiring harness and lighted rocker switch. When it comes to reliability, Toro delivers replacement parts designed to the exact engineering specifications of our equipment. For peace of mind, insist on Toro genuine parts.
Z593 MUSTERBERICHT (Part # 111-5135)
TUV KIT INSTRUCTIONS (Part # 111-5244)
TUV KIT INSTRUCTIONS (Part # 111-5911)
Z593 MANUFACTURERS CERTIFICATE (Part # 111-5967)
Hypr-Oil™ 500 (quart) (Part # 114-4713)
Hypr-oil™ 500 (quart). Toro Hypr-Oil 500 is a high-performance hydraulic fluid specifically formulated and approved by Toro engineering for use in Toro commercial zero turn mowers. It provides excellent wear and corrosion protection for hydraulic systems, helping to maintain consistent performance and extend the service life of hydraulic components. Always refer to your operator manual for the correct fluid specification and service intervals.
Hypr-Oil™ 500 (gallon) (Part # 114-4714)
Toro Hypr-Oil 500 is a high-performance hydraulic fluid specifically formulated and approved by Toro engineering for use in Toro commercial zero turn and stand-on mower hydraulic systems. Maintaining the correct hydraulic fluid and changing it at the manufacturer-recommended interval is critical to protecting hydraulic pumps, wheel motors, and other hydraulic components from wear and corrosion — particularly on machines operating under commercial duty cycles. Refer to your operator manual for the correct change interval and fluid capacity for your equipment.
Hypr-Oil™ 500 Hydraulic Oil (5 gallon) (Part # 114-4715)
Toro Hypr-Oil 500 is a high-performance hydraulic fluid formulated and approved by Toro engineering for commercial zero turn and stand-on mower hydraulic systems. The 5-gallon commercial bulk pack is designed for fleet operators and service shops performing multiple machine hydraulic fluid changes. Maintaining the correct hydraulic fluid on schedule protects pumps, wheel motors, and other hydraulic components from accelerated wear. Refer to your operator manual for the correct change interval and capacity for each machine. Do not mix with other hydraulic fluids.
Bimini Folding Sunshade Assembly (Part # 115-4510)
Toro genuine Optional fabric sun shade provides protection and comfort by shielding the operator from the elements. Verify your model and serial number to confirm compatibility before ordering.
Seat Cover w/Arm Rest (Part # 117-0095)
This genuine Toro OEM seat cover with arm rest is designed to fit Toro Z-Master zero turn mowers and serves a dual purpose: protecting the operator seat from UV and wear from day one, or replacing a worn or damaged seat cover as a wear-and-tear item. The arm rest addition improves operator comfort significantly during longer mowing sessions. Verify your model and serial number before ordering.
18 Inch Hi-Flow Blade (Part # 140-1242)
This Toro OEM 18-inch Hi-Flow replacement mower blade is designed to produce high lift, cutting grass cleanly and propelling clippings upward and out through the discharge chute. Hi-Flow blades — also referred to as basic, standard, or 2-in-1 blades — are the preferred choice when using a grass catcher or bagger, as the increased airflow drives clippings efficiently into the collection bag. This blade is compatible with multiple Toro riding lawn mowers models — always verify your model and serial number before ordering to confirm the correct fit.
18 Inch Medium Flow Mower Blade (Part # 140-4856)
Toro 18 Inch OEM Medium Flow blade. Medium Flow mower straight edge, standard discharge blade. These blades have slight upward angle on the edges. Great blades for use when horsepower is a concern. Produce medium Flow but requires less horsepower than Hi-Flow blades. This Toro blade has multiple applications. Be sure to verify model and serial number to ensure the correct part.
18 Inch Low Flow Mower Blade (Part # 140-4857)
This Toro OEM 18-inch Low Flow replacement mower blade features a slightly curved tip design that keeps airflow to a minimum during operation. Low Flow blades are the right choice for mowing in sandy, dusty, or dry conditions where high suction would stir up excessive debris — they also cause less strain on the engine than Hi-Flow blades, making them a practical option when horsepower is a consideration. Compatible with multiple Toro riding lawn mowers models — verify your model and serial number before ordering.
18 Inch Atomic Blade (Part # 140-4858)
This Toro OEM 18-inch Atomic replacement blade — commonly known as a Gator-style blade — features a serrated cutting edge with raised teeth that shred grass clippings into much finer pieces than a standard mulching blade. The serrated design re-cuts clippings multiple times on every pass, delivering the highest mulching quality available and a consistently crisp, clean cut even in dense or damp grass. Compatible with multiple Toro riding lawn mowers models — verify your model and serial number before ordering.
18 Inch Recycler Blade (Part # 140-4859)
This Toro OEM 18-inch Recycler replacement mower blade is built to work within Toro's Recycler mulching system, featuring uniquely shaped 'accelerator' wings that act as a fan to keep clippings circulating beneath the deck. As clippings are forced back into the cutting zone, they are re-cut multiple times into fine pieces that fall back into the lawn and break down into natural fertilizer — feeding the grass and reducing the need to bag or rake. Compatible with multiple Toro riding lawn mowers models — verify your model and serial number before ordering.
Hi-Flow 18 Inch Blade Pack (6) (Part # 140-4882)
This Toro OEM 18-inch Hi-Flow replacement mower blade — sold as a pack of 6 is designed to produce high lift, cutting grass cleanly and propelling clippings upward and out through the discharge chute. Hi-Flow blades — also referred to as basic, standard, or 2-in-1 blades — are the preferred choice when using a grass catcher or bagger, as the increased airflow drives clippings efficiently into the collection bag. This blade is compatible with multiple Toro riding lawn mowers models — always verify your model and serial number before ordering to confirm the correct fit.
Mid Flow 18 Inch Blade Pack (6) (Part # 140-4883)
This Toro OEM 18-inch Mid Flow replacement mower blade — sold as a pack of 6 is engineered to provide a balance between the high suction of Hi-Flow blades and the minimal airflow of Low Flow blades. Mid Flow blades have a slight upward angle on the cutting edges, producing moderate lift while requiring less horsepower than Hi-Flow blades — making them a versatile option for varied terrain and grass conditions. Compatible with multiple Toro riding lawn mowers models — verify your model and serial number before ordering.
Low Flow 18 Inch Blade Pack (6) (Part # 140-4884)
This Toro OEM 18-inch Low Flow replacement mower blade — sold as a pack of 6 features a slightly curved tip design that keeps airflow to a minimum during operation. Low Flow blades are the right choice for mowing in sandy, dusty, or dry conditions where high suction would stir up excessive debris — they also cause less strain on the engine than Hi-Flow blades, making them a practical option when horsepower is a consideration. Compatible with multiple Toro riding lawn mowers models — verify your model and serial number before ordering.
Atomic 18 Inch Blade Pack (6) (Part # 140-4885)
This Toro OEM 18-inch Atomic replacement blade — commonly known as a Gator-style blade — features a serrated cutting edge with raised teeth that shred grass clippings into much finer pieces than a standard mulching blade. The serrated design re-cuts clippings multiple times on every pass, delivering the highest mulching quality available and a consistently crisp, clean cut even in dense or damp grass. Compatible with multiple Toro riding lawn mowers models — verify your model and serial number before ordering.
Recycler 18 Inch Blade Pack (6) (Part # 140-4886)
This Toro OEM 18-inch Recycler replacement mower blade — sold as a pack of 6 is built to work within Toro's Recycler mulching system, featuring uniquely shaped 'accelerator' wings that act as a fan to keep clippings circulating beneath the deck. As clippings are forced back into the cutting zone, they are re-cut multiple times into fine pieces that fall back into the lawn and break down into natural fertilizer — feeding the grass and reducing the need to bag or rake. Compatible with multiple Toro riding lawn mowers models — verify your model and serial number before ordering.
Filter Gauge for Kohler Engines (Part # 99-4664)
Toro genuine filter gauge. Toro would like to remind you that fitment can vary by sub model, serial number, and/or production date of your equipment. Verify your model and serial number to confirm compatibility before ordering.
Hitch Kit (Part # 99-8925)
Add versatility to your Toro Z-Master with this easy to install hitch kit . This genuine Toro part provides towing capability for spreaders, carts and other attachments.
-
Model #
72279TE -
Serial #
406397919 - 406399999 -
Product Name
Z Master Professional 7000 Series Riding Mower, With 132cm TURBO FORCE Rear Discharge Mower -
Product Brand
Toro -
Product Type
Riding Products -
Product Series
Zero Radius Turn, Professional 7000 Series -
Chassis Type
ZRT - LCE -
Swath
52in/132cm -
Discharge
Rear Discharge -
Engine/Motor Manufacturer
Kubota -
Engine/Motor Size
23 hp -
Engine/Motor Type
4 Cycle Diesel -
Engine Starter
Electric -
Transmission Type
Hydrostatic -
Traction Type
Rear WD
-
Chassis: Height of Cut Range
1.5" - 5" (38-127mm) -
Chassis: Tire Pressure
13 psi / 90 kPa -
Engine: Battery
12V 540 CCA -
Engine: Engine Oil Type
w/filter chg 3.9 qt. / 3.7L, SAE20, 10w30, 10w40 -
Drive System: Gearbox Lubricant
132 oz. (3.9 liters) 15w50 synthetic motor oil -
Engine: Engine Speed
3350+20/-50 RPM -
Drive System: Ground Speed
0-11 mph / 0-17.5kph
